XCMG mini skidsteer loaders XC740K 1 ton China new skid steer loader
Summary
- Rated Load:750kg
- Dimension(Long*Breadth*High):3270*1807*1970mm
- Type:Skid Steer Loader
- Place of Origin:Xuzhou, Jiangsu, China
- Model Number:XC740K
- Brand Name:XCMG
- Certification:CE/ISO90001
Specifications
- Weight:3140.000kg
- Condition:New
- Moving Type:Other
- Machine Weight:3140kg
- Power:36.8KW
- Engine Brand:XINCHAI
- Bucket capacity:0.35M3
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG mini skidsteer loaders XC740K 1 ton China new skid steer loader.
XC740K with strong power and rich attachments, the XCMG skid-steer loader can better adapt to the operations in narrow space and is an ideal tool for road construction, municipal maintenance, port handling, garden maintenance, and pasture production, featuring low operation cost and remarkable economic benefits.
Performance Characteristics:
1, The renowned brand engine equipped features strong power, ultra-low emission, and higher fuel efficiency.
2, Compact structure, low turning radius, and strong site adaptability.
3, The international interchangeable quick-change coupling enables the change of tens of attachments, including sweeper, planer, breaking hammer, and ditcher, rapidly and conveniently.
4, The ROPS&FOPS cab and the seat belt, bumper, fire extinguisher, and safety hammer equipped guarantee the personal safety of the operator.
5, The cab can be tilted backward for a large angle to make the repair and maintenance portions more accessible.
|
Description |
Unit |
Parameter value |
|
|
Rated load |
kg |
750 |
|
|
Tipping load |
kg |
1500 |
|
|
Operating weight |
kg |
3140 |
|
|
Maximum breakout force |
kN |
18 |
|
|
Engine |
Manufacturer |
Xinchai |
|
|
Model |
4D27G31 |
||
|
Rated power |
Hp/kw |
49.3/36.8 |
|
|
Rated speed |
rpm |
2500 |
|
|
Cooling mode |
Water-cooling |
||
|
Maximum speed |
Km/h |
14 |
|
|
Hydraulic system |
Hydraulic flow rate |
L/min |
62.5 |
|
Hydraulic pressure |
bar |
200 |
|
|
Maximum operating height |
mm |
3878 |
|
|
Length without bucket |
mm |
2533 |
|
|
Length with bucket |
mm |
3310 |
|
|
Maximum unloading height |
mm |
2375 |
|
|
Ground-bucket angle |
° |
30 |
|
|
Rotating angle of bucket at highest point |
° |
83 |
|
|
Unloading distance |
mm |
575 |
|
|
Wheel base |
mm |
1027 |
|
|
Departure angle |
° |
25 |
|
|
Length of tail |
mm |
1005 |
|
|
Wheel track |
mm |
1380 |
|
|
Bucket capacity (stacking height) |
m³ |
0.45 |
|
|
Bucket capacity (tiling) |
m³ |
0.35 |
|
|
Diesel tank capacity |
L |
80 |
|
|
Capacity of hydraulic oil tank |
L |
60 |
|
