XCMG 150KW rotary drilling rig XR130E price

FOB Price: $10000.00-$1000000.00

View All >

Model： XR130E

Engine： Cummins

After-sales Service： Engineers available to service machinery overseas

Min Order Quantity： 1 Unit

Delivery Time：

In Stock (Within 7 days)

Production (Within15 to 20 days)

Customization (negociated delivery time)

After-sales Service：

1. It is recommended that you keep in touch with the seller after purchasing offline...

About after-sales service:

1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:

1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.

Inquiry Chat Now

Favorite Products

Product:

XCMG 150KW rotary drilling rig XR130E price

Quantity:

- + /EA

Content:

Or choose from these questions:

What is the best price you can offer?

Do you support customization?

What is the MOQ for this product?

*Email:

Full Name:

Mobile phone:

XR130E

Specs & Compare

Details

Specs & Compare

Select 3 models for comparison

Certification

Dimension(L*W*H)

Weight

Power(W)

Voltage

Usage

Model Number

Brand Name

Place of Origin

Power Type

Type

Engineering & Construction Machinery

XR130E

CE/ISO9001

7546*3600*17724mm

45000kg

150KW

XR130E

XCMG

Xuzhou, Jiangsu,China

Diesel

+ Add a Product

Summary

Certification:CE/ISO9001
Dimension(L*W*H):7546*3600*17724mm
Weight:45000kg
Power(W):150KW
Model Number:XR130E
Brand Name:XCMG
Place of Origin:Xuzhou, Jiangsu,China
Power Type:Diesel

Specifications

Weight:45000.000kg
Condition:New
Moving Type:Crawler
Drilling Diameter:2500mm
Max.pulling force:50kN

Packaging & Shipping

Delivery Lead Time:7 days for ready goods
Minimum Order:1 Piece
Supply Ability:10,000 Set/ Sets per Month
Total Quantity In Stock:Over 5000
Delivery Port:Any Port In China

XCMG 150KW rotary drilling rig XR130E price

XCMG 150KW rotary drilling rig XR130E.

XCMG rotary drilling rig XR130E stands for our company's achievement in many years' development and researches on piling machine, adopting the advanced technology, both at home and abroad.

With our company's powerful machinery manufacturing capacity, XCMG rotary drilling rig XR130E is specially designed to drill the pile hole with the big diameter and into hard—layers, fitting for layer conditions in most areas.

Performance Characteristics:

1.XCMG rotary drilling rig XR130E adopts dedicated TDP series hydraulic retractable chassis and large—diameter slewing bearing and has high stability and convenience of transport It has long wheel base which makes it very adaptable to the terrain.

2. Transportation of the machine includes a drilling bar. Transportation width is only 2.5m and transportation height is only 3.5 m. Light transport weight makes easier to load and unload.

3. Rotary drive, main winch and auxiliary winch have high output speed, which develops the efficiency of work.

4. XCMG rotary drilling rig XR130E adopts guangxi cummins turbocharged engine with electro—control which provides strong power and meets the requirements of EU3 emission standard, can select imported engine of cummins.

5. XCMG rotary drilling rig XR130E adopts imported Kawasaki hydraulic system with high reliability and a lot of technology of XCMG.

6. XCMG rotary drilling rig XR130E adopts the technology of CAN electronic control and simplify the hydraulic plumbing system which improves the reliability of the machine.

7. A variety of specifications configuration of drilling bars are available which meets the needs of different working conditions.

8. Cylinder crowded, winch crowded, drive of casing pipe, CFA, spin—off type function are optional.

XCMG 150KW rotary drilling rig XR130E price

Description		Unit	Parameter value
Max. drilling diameter		mm	1500
Max. drilling depth		m	56
Allowable luffing scope (from center of drill rod to slewing center)		mm	3250～3650
Drilling rig dimension in working condition (L × W × H)		mm	7550×4200×19040
Drilling rig dimension in transport condition (L × W × H)		mm	13150×2960×3140
Weight of overall unit (standard configuration, excluding drilling tool)		t	49
Engine	Model		CUMMINS QSB7
Engine	Rated power/speed	kW	150/（2050r/min）
Max. working pressure of hydraulic system		MPa	35
Rotary drive	Max. torque	kN •m	150
Rotary drive	Rotational speed	r/min	7～33
Crowd cylinder	Max. Pushing force	kN	120
	Max. Pulling force	kN	160
	Max.stroke	mm	3500
Main winch	Max.pulling force	kN	160
	Max. single-rope speed	m/min	72
	Diameter of the steel wire rope	mm	26
Auxiliary winch	Max.pulling force	kN	50
	Max. single-rope speed	m/min	60
	Diameter of the steel wire rope	mm	16
Rotary table slewing angle		°	360
Traveling	Max. traveling speed of the overall unit	km/h	2.1
Traveling	Max. climbable gradient of the overall unit	%	40
Crawler	Width of crawler plate	mm	700
	External width of crawler (min.-max.)	mm	2960～4200
	Center distance between two longitudinal wheels of crawler	mm	4310
	Average ground pressure	kPa	83
