XCMG Mobile Hydraulic All Terrain Truck Crane XCA1600 with Telescoping Boom
Summary
- Model Number:XCA1600
- Brand Name:XCMG
- Place of Origin:Jiangsu, China
- Span: 360
- Max. Lifting Load:1600T
- Rated Loading Capacity:1600T
- Application: Construction works
- Certification:CE ISO9001
Specifications
- Weight:16000000.000kg
- Condition:New
- Moving Type:Other
- Color:Red
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG Mobile Hydraulic All Terrain Truck Crane XCA1600 with Telescoping Boom
• XCA1600 new terrain crane integrates 222 patent techniques, adopts 38 new patents techniques, and shows 8 technical highlights.
• The overall length in travel is only 15.77m, the weight is 60t, the chassis length is 13.77m, and the minimum turning radius is 10m. The whole configuration includes 6-segment boom with the length of 62m and 3-segment jib with the length of 28m. 6 counterweight combinations can finish nearly 30000 working conditions.
• Adopt the imported EFI engine with strong power system and imported 12-gear automatic control transmission. The 2nd, 4th, and 5th axles are the drive axle. The steering form is 10x10 full-axle steering.
• Adopt new single cylinder retractable technique and high-intensity imported steel, featuring lighter dead-weight and stronger performance.
• The self-combination counterweight technique developed by ourselves can effectively improve the lifting performance by 30%.
• The electrohydraulic proportion control multi-axle steering mode can realize many kinds of steering modes.
• The new brake technique can reduce 2/3 maintenance cost, and improve the travel safety.
• The comfortable cabs and outrigger operation completely show the humanity design concept.
• Equip with the XCM unique control system, auxiliary retractable boom system, virtual wall system, perfect failure diagnosis, real-time detection, CAN technique, etc.
| Item | Unit | Parameter |
| Max. rated lifting capacity | t | 1600 |
| Max.lifting height | m | 155 |
| Max. travel speed | km/h | 80 |
| Grade ability under heavy load | % | 30 |
| Engine rated power | kW /(r/min) | 480/1800 |
