XCMG GR2003 China Brand New Road Motor Grader Machine

FOB Price: $50000.00-$70000.00

View All >

Model： GR2003

Engine： Cummins

After-sales Service： Engineers available to service machinery overseas

Min Order Quantity： 1 Unit

Delivery Time：

In Stock (Within 7 days)

Production (Within15 to 20 days)

Customization (negociated delivery time)

After-sales Service：

1. It is recommended that you keep in touch with the seller after purchasing offline...

About after-sales service:

1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:

1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.

Inquiry Chat Now

Favorite Products

Product:

XCMG GR2003 China Brand New Road Motor Grader Machine

Quantity:

- + /EA

Content:

Or choose from these questions:

What is the best price you can offer?

Do you support customization?

What is the MOQ for this product?

*Email:

Full Name:

Mobile phone:

GR2003

Specs & Compare

Details

Specifications

Weight:16000.000kg
Condition:New
Moving Type:Other
Weight:16000kg
Dimension(L*W*H):8900*2625*3420mm
Engine Brand:Cummins
Forward Speed:38km/h
Reverse Speed:23km/h
Minimum Turning Radius:7.3m
Ground Clearance (Front Axle):430mm
Working System Pressure:20MPa

Packaging & Shipping

Delivery Lead Time:7 days for ready goods
Minimum Order:1 Piece
Supply Ability:10,000 Set/ Sets per Month
Total Quantity In Stock:Over 5000
Delivery Port:Any Port In China

XCMG GR2003 China Brand New Road Motor Grader Machine

XCMG GR2003 China Brand New Road Motor Grader Machine.

The motor grader is mainly used for ground leveling, ditching, slope scraping, bulldozing, scarification, snow removal for large areas such as highway, airports, farmlands etc. It is the necessary construction machinery for national defense construction, mine construction, urban and rural road construction and water conservancy construction, farmland improvement and so on.

Advantages and Highlights:

1.Energy-saving and noise-reducing: adopt low-speed engine transmission line, low specific fuel consumption of rated point, energy saving and environmental protection; low-speed ratio configuration of transmission system, average fuel consumption reduced by about 8%.

2.Strong Power: Adopting Sichai High-efficiency State III Variable Power Engine.

3.With load rotation: to improve the hydraulic system pressure, blade rotary force greatly improved, high-frequency quenching gear ring, wear resistance and life expectancy, to achieve load rotation.

4.Efficient operation: The displacement of the hydraulic pump and the hydraulic motor is increased.

XCMG GR2003 China Brand New Road Motor Grader Machine

Item			GR2003
Basic parameters	Engine model		SC9DK200.1G3
	Rated power/speed		147kW/2200rpm
	Overall dimension (standard)		8900x2625x3420mm
	Total weight (standard)		16000 kg
	Tire specification		17.5-25
	Ground clearance (front axle)		430mm
	Tread		2156mm
	Space of front and rear axles		6219 mm
	Space of middle and rear wheels		1538 mm
Performance parameters	Forward velocity		5/8/11/19/23/38km/h
	Reverse speed		5/11/23km/h
	Tractive effort f=0.75		82 kN
	Maximum gradeability		25%
	Tire inflation pressure		260kPa
	Working system pressure		20MPa
	Transmission pressure		1.3-1.8Mpa
Working parameters	Maximum steering angle of front wheel		±48°
	Maximum slant angle of front wheel		±17°
	Maximum oscillating angle of front axle		±15°
	Maximum oscillating angle of equilibrium box		±15°
	Maximum steering angle of frame		±27°
	Minimum turning radius		7.3m
	Scrape knife	Maximum lift height	400mm
		Maximum cutting depth	500mm
		Maximum tilt angle	90°
		Cutting angle	28°-70°
		Angle of revolution	360°
		Length & chord height	4270x610mm
Oil filling amount	Coolant		50L
	Fuel tank		280L
	Engine		24L
	Transmission		38L
	Balancing box		46L
	Drive axle		28L
