XCMG 16 ton mining wheel bulldozers dozer DL210KN with high quality
Specifications
- Weight:16900.000kg
- Dimension(Long*Breadth*High):7430*3354*3515mm
- Machine Weight:16900kg
- Rated power:162kw
- Engine Brand:WEICHAI
- Wheel base :3410mm
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG 16 ton mining wheel bulldozers dozer DL210KN with high quality.
DL210KN mining wheel bulldozers is an industry-leading high-end model built elaborately by XCMG and XCMG owns the proprietary intellectual property rights for all of its core parts. Featuring high mobility and powerful bulldozing force, this product is a kind of multi-purpose and high-efficiency construction machinery that can be used for the rapid clear-up of land and road structures and is applicable for the disaster relief and roadblock clear-up applications.
1.Full hydraulic steering, power shift speed, hydraulic control work device, light operation, flexible and comfortable.
2.Working device using box-like structure of the push arm, push the length, adjustable length of the link structure, the ball link.
3.Chain block construction machinery drive shaft, impact resistance, power transmission reliability.
4.Button release of gas pressure protection and emergency braking integration, safe and reliable.
5.Good maneuverability, easy transfer of work, no damage to the road.
6.Optional new air-conditioned luxury cab, vision, sealed vibration, good operating environment.
|
Description |
Unit |
DL210KN |
|
|
Dozer Max.lift heigh |
mm |
1000 |
|
|
Dozer Max.cutting depth |
mm |
380 |
|
|
Dozer Max.titing range |
mm |
500 |
|
|
Max.drawing force |
kN |
136 |
|
|
Articulation angle |
。 |
36 |
|
|
Min.turn radius |
mm |
6985 |
|
|
Climb ability |
。 |
30 |
|
|
Wheel base |
mm |
3410 |
|
|
Tread |
mm |
2180 |
|
|
Speeds |
1st（F/R） |
km/h |
13/17 |
|
2st（F） |
km/h |
40 |
|
|
Engine Model |
WD10G220E21 |
||
|
Rated power/speed |
kW/(r/min) |
162 |
|
|
LxWxH |
mm |
7430X3354X3515 |
|
|
Operating weight |
t |
16.5 |
|
|
Tires |
23.5-2.5 |
||
