XCMG official 1m XM1003H concrete milling machine scarifying for sale
Summary
- Dimension(L*W*H):4600*2414*3000mm
- Weight:15800kg
- Power(W):164kw
- Model Number:XM1003H
- Brand Name:XCMG
- Place of Origin:Xuzhou, Jiangsu, China
- Milling width (mm):1000mm
- Milling depth (mm):225mm
- Certification:CE/ISO9001
Specifications
- Weight:15800.000kg
- Condition:New
- Moving Type:Other
- Fuel tank:370L
- Travel speed:8km/h
- Gradeability:85%
- Rated speed:2200rpm
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG official 1m XM1003H concrete milling machine scarifying.
XCMG XM1003H concrete milling machine scarifying is the maintenance construction machinery of asphalt concrete pavement, mainly used for excavation and renovation of highway, urban road, airport, freight yard, parking lot and other large area of asphalt concrete pavement.
The equipment has high working efficiency, simple construction technology, and the milling depth is easy to control, convenient and flexible, good maneuvering performance, and direct recycle of old milling material, can be widely used for maintenance and renovation of the asphalt pavement.
|
Model |
Unit |
XM1003H |
|
|
|
Max. milling with |
mm |
1000 |
|
|
Max. milling depth |
mm |
255 |
|
Milling wheel |
Number of tools |
|
80 |
|
Drum diameter with tools |
mm |
860 |
|
|
Engine |
Model |
|
Commins ,QSB6.7 |
|
Rated power |
kW |
164 |
|
|
Rated speed |
rpm |
2200 |
|
|
Specifications |
Operating speed |
m/min |
40 |
|
Travel speed |
km/h |
8 |
|
|
Ground clearance |
% |
85 |
|
|
Ground clearance |
mm |
180 |
|
|
Operating weight |
kg |
15800 |
|
|
Volume |
Fuel tank |
L |
370 |
|
Hydraulic oil tank |
L |
120 |
|
|
Water tank |
L |
900 |
|
|
Measurement |
Overall machinery L*W*H |
mm |
4600*2414*3000 |
|
Conveyor LxWxH |
mm |
7920*1100*980 |
|
|
Travel mode |
|
Tire |
|
