HOWO 6000 liters concrete mixer truck G06K price
Summary
- Dimension(L*W*H):8240*2500*3740mm
- Power(W):247kw
- Place of Origin:XUZHOU,CHINA
Specifications
- Weight:14000.000kg
- Condition:New
- Moving Type:Other
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
HOWO 6000 liters concrete mixer truck G06K .
HOWO 6000 liters concrete mixer truck Particular mixing technology with continuous trace, original double log spiral technology with changeable lift angle and changeable screw pitch and optimized auxiliary blades and pressure-reducing hole design can make the operation path of the spiral in perfect state and can ensure the best concrete flowing trend in mixing drum and more uniformly discharging. It can effectively solve the blocking problems in concrete pumps caused by nonuniform concrete.
HOWO 6000 liters concrete mixer truck Optimized chassis matches with upper parts and such parts as front base and accessory beam, rear base and tilted beam, rear base and accessory beam adopt integration design.
HOWO 6000 liters concrete mixer truck Hydraulic pump, motor and speed reducer of such world-famous brands as ZF, Rexroth, Bonfiglioli, PMP, TOP are adopted to make the power more sufficient, system steadier and more reliable and service life longer.
HOWO 6000 liters concrete mixer truck design concept is adopted, and the high-strength connecting bolts are arranged, and the connection is reliable and durable; the mixing drum is made of high-strength wear-resistant material, and the frame is made of high-strength steel, which has stronger carrying capacity and long service life;
The front and rear axles adopt enlarged and widened brakes, and the braking distance of the whole vehicle is shorter; the synchronous design of the upper chassis and the simulation of the multi-function calculation of the upper loading and the chassis are supplemented by the reliability test of the prototype 10,000 km to ensure safety and reliability;
Strong power; sophisticated technical matching, fuel-saving and environmental protection; increased flow air filter, optimized intake resistance, filtration efficiency is 30% higher than ordinary mixers;
Closed hydraulic system, easy to operate, easy to achieve stepless speed regulation, high efficiency, small reversing impact force; minimum turning diameter of 16m, flexible turning, convenient access; vertical structure headlights, beautiful atmosphere, wider range of illumination.
|
Category |
Model |
Unit |
G06K |
|
Performance of mixing drum |
Geometric volume |
m³ |
11.6 |
|
Max. diameter of drum |
mm |
2250 |
|
|
Drum length |
mm |
4217 |
|
|
Mounting tilt angle |
° |
15 |
|
|
Rotary speed |
r/min |
0~14 |
|
|
Charging speed |
m³/min |
≥3 |
|
|
Discharging speed |
m³/min |
≥2 |
|
|
Residual ratio of discharging |
% |
<0.7 |
|
|
Range of slump |
cm |
5~21 |
|
|
Hydraulic system |
Oil pump |
|
World-famous brand |
|
Motor |
|
World-famous brand |
|
|
Speed reducer |
|
World-famous brand |
|
|
Hydraulic circuit |
|
Closed type |
|
|
Water supply |
Volume of water tank |
L |
450 |
|
Way of water supply |
|
Air pressure |
|
|
Overall machine |
Chassis brand |
|
SinoTruck |
|
Chassis model |
|
ZZ1255N3246B1 |
|
|
Steering wheel |
|
Left steering wheel |
|
|
Curb mass |
kg |
12250 |
|
|
Driving type |
|
6×4 |
|
|
Wheelbase |
mm |
3225+1350 |
|
|
PTO way |
|
Flywheel PTO |
|
|
Outline dimension |
(L*W*H)mm |
8240*2500*3740 |
|
|
Engine |
Model |
|
WD615.69 |
|
Rated power |
Kw/r/min |
247 |
|
|
Displacement |
L |
9.726 |
|
|
Emission standard |
|
II |
