Specifications
- Weight:1200.000kg
- Condition:New
- Type:Open Frame
- Engine Brand:Cummins
- Power Range:10-200KW
- Rated Power:58KW/72KVA
- Rated voltage:400/230 V
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
|
One the main parameters of the set |
|
|
The model of the unit |
XHZC-58GF |
|
Rated Power |
58KW/72KVA |
|
Standby power |
64KW/80KVA |
|
Rated voltage |
400/230 V |
|
Rated current |
105A |
|
Frequency/Speed |
50Hz/1500RPM |
|
The waste of fuel with full load |
208g/kw.h |
|
Engine specification |
|
|
Engine |
Cummins |
|
Brand |
DCEC |
|
Model |
4BTA3.9-G11 |
|
Rated Power |
70KW/88KVA |
|
Standby power |
80KW/100KVA |
|
No. of Cylinders |
4 |
|
Type |
4 cycle |
|
Aspiration |
Turbochanger& Aftercooler |
|
Standby power |
50Hz/1500RPM |
|
Bore*Storke: |
102 *120MM |
|
Displacement |
3.9 L |
|
Compression Ratio |
17.3:1 |
|
Lubricating oil capacity |
11L |
|
Cooling system |
22L |
|
Starting way |
DC24V starting with electricity |
|
Alternator specification |
|
|
Brand |
XHZ |
|
Place of production |
Jiangsu |
|
Model |
WXHZ-58 |
|
Type |
brushles |
|
The connecting way of the phase |
three phase four lines |
|
Frequency/Speed |
50Hz/1500RPM |
|
Insulation degree |
H degree |
|
Grading Protection |
IP23 |
|
Winding connection |
Star |
|
Voltage regulator type |
AVR |
|
Bearing |
Single Bearing |
|
Coating |
Vacuum impregnation |
|
coupling |
Flexible disc |
|
Control system introduction |
||
|
Brand |
Smartgen |
|
|
Place of production |
ZhengZhou |
|
|
Model |
HGM6110series |
|
|
HGM6110series automatic controller, integrating digital, intelligent and network techniques, is used for automatic control and monitoring system of single genset. It can carry out functions of automatic start/stop, data measurement, alarm protection and “three remote” (remote control, remote measurement and remote communication). The controller uses LCD display, optional language interface including Chinese, English, Spanish, Russian, Portuguese, Turkish, Polish and French with easy and reliable operation. HGM6110series automatic controller uses micro-processing technique which can achieve precision measurement, value adjustment, timing and threshold setting etc. All the parameters can be configured from front panel or use USB interface (or RS485 interface) to adjust via PC. It can be widely used in all types of automatic control system for its compact structure, simple connections and high reliability. |
||
|
|
||
|
Mains |
Generator |
|
|
Line voltage (Uab, Ubc, and Uca) |
Line voltage (Uab, Ubc, and Uca) |
|
|
Phase voltage (Ua, Ub, and Uc) |
Phase voltage (Ua, Ub, and Uc) |
|
|
Frequency HZ |
Frequency HZ |
|
|
Voltage regulator type |
AVR |
|
|
Load |
||
|
Current IA, IB, IC |
Active power KW |
|
|
Reactive power KVar |
Apparent power KVA |
|
|
Power factor PF |
Generator accumulated energy kWh |
|
|
Mains have functions of over/under voltage and lack of phase; Gens have functions of over/under voltage, over/under frequency and over current; |
||
|
Precision measure and display of parameters about engine |
||
|
Temp. (WT) |
°C/ °F both are displayed |
|
|
Oil pressure (OP) |
kPa/Psi/Bar are all displayed |
|
|
Fuel level (FL) |
% |
|
|
Speed (SPD), |
RPM |
|
|
Battery Voltage (VB) |
V |
|
|
Charger Voltage (VD) |
V |
|
