XCMG official 35 ton truck crane QY35K5-I for sale
Summary
- Model Number:QY35K5-I
- Brand Name:XCMG
- Place of Origin:Xuzhou,Jiangsu,China
- Max. Lifting Height:46.8m
- Max. Lifting Load:35ton
- Application:Construction
- Certification:CE/ISO9001
Specifications
- Weight:31750.000kg
- Condition:New
- Moving Type:Wheel
- Rated power:206/2200kW/(r/min)
- Max. output torque:1112/1400N.m/(t/min)
- Dimensions:12300*2500*3350mm
- Max. travel speed:80km/h
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG official 35 ton truck crane QY35K5-I.
XCMG truck crane QY35K5-I excellent welding technology for structural members. Welding robot with advance process used for key welding make reliable quality products.
Performance Characteristics:
1. Specialized boom of octagonal cross section has features of light deadweight, better strength and strong lifting capacity.
2. Advanced built-in boom head, strong structural members and lower sliders with larger area contribute to better stress-bearing capacity and more smooth telescoping movement, and efficiently prevent boom torsion after side loading.
3. Telescoping mechanism is designed reliably. In the telescoping mechanism, both rotation-resistant rope used for thick cable and guide pulley bearing are imported parts and have reliable performance.
4. Ferrule-type compression joints are used for pipeline, have features of reliable connection, better tightness and less leakage.
| Description | Unit | Parameter value | |
| Overall length | mm | 12300 | |
| Overall width | mm | 2500 | |
| Overall Height | mm | 3350 | |
| Wheel Base | mm | 4425+1350 | |
| Track | mm | 2074/1834/1834 | |
| Total vehicle mass in travel configuration | kg | 31750 | |
| Axle load | Front axle | kg | 6550 |
| Rear axle | 25200 | ||
| Engine Model | SC8DK280Q3 | ||
| Engine rated power | kw/(r/min) | 206/2200 | |
| Engine rated torque | N.m/(r/min) | 1112/1400 | |
| Max. travel speed | km/h | 80 | |
| Min. turning diameter | m | 22 | |
| Min. ground clearance | mm | 275 | |
| Max. grade ability | % | 40 | |
| Approach angle | ° | 16 | |
| Departure angle | ° | 13 | |
| Braking distance (at 30 km/h, full load ) | m | ≤10 | |
| Oil consumption per 100km | L | ≤37 | |
| Exterior noise level during acceleration traveling | dB (A) | 88 | |
| Noise level at seated position | dB (A) | 90 | |
