XCMG official 240HP China motor grader GR2405 for sale
![](/app/topc/statics/images/close.png)
![XCMG official 240HP China motor grader GR2405 for sale](http://www.machmall.com/images/store/357636/item/fba8daa1c5a3e795862c4d44cb5986e8.jpg)
![](/app/topc/statics/images/close.png)
Specifications
- weight:16700.000kg
- Condition:New
- Moving Type:Other
- Rated power/speed:178/2200kW/rpm
- Traction force (f=0.75):88kN
- Min.turing radius:7.3m
- Moldboard width×height:3965×610mm
- Brand Name:XCMG
- Place of Origin:Jiangsu, China
- Certification:CE/ISO9001
- Weight:16700kg
- Dimension:9300*2625*3470mm
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG official 240HP China motor grader GR2405.
XCMG GR series motor graders cover a wide range of models, including small type, conventional type,mining type, type for cold zone, desert and plateau as well as CE certified series. There are mainly models of GR165 / GR180 / GR200 / GR215 / GR230 / GR2405.
XCMG motor grader GR2405 is mainly used for ground leveling, ditching, slope scraping, bulldozing, scarification, snow removal for large areas such as highway, airports, farmlands etc.
XCMG motor grader GR2405 is the necessary construction machinery for national defense construction, mine construction, urban and rural road construction and water conservancy construction, farmland improvement and so on.
The main performance characteristics of XCMG motor grader GR2405 include:
1. Utilizing load sensitive hydraulic system, small control force, good control feeling, realizing micro control.
2. Engine variable power control technology, more energy efficient.
3. Wet type brake axle, long lifetime, higher reliability.
4. The working device is more reliable with the integral angle position device, high strength rotary support and overload protection worm gearbox.
Market share of XCMG motor grader:
XCMG GR series motor graders are leading the industry, and their Chinese market share and export volume have been ranked first in the industry for four consecutive years.
Item |
Unit |
GR2405 |
||
Basic parameters |
Engine model |
|
QSB6.7 |
|
Rated power/speed |
kW/rpm |
178/2200 |
||
Overall dimension(standard) |
mm |
9300 x 2625 x 3470 |
||
Total weight(standard) |
kg |
17000 |
||
Tire specification |
|
17.5-25 |
||
Ground clearance |
mm |
586 |
||
Tread |
mm |
2156 |
||
Space of front and rear axles |
mm |
6447 |
||
Space of middle and rear wheels |
mm |
1538 |
||
Performance parameters |
Forward velocity |
km/h |
5、8、11、18、25、40 |
|
Reverse speed |
km/h |
5、11、25 |
||
Tractive effort f=0.75 |
kN |
≥88 |
||
Maximum gradeadbility |
% |
≥25 |
||
Inflation pressure of tires |
kPa |
260 |
||
Working system pressure |
MPa |
22 |
||
Transmission pressure |
MPa |
1.85-2.2 |
||
Working parameters |
Maximum steering angle of front wheels |
° |
±48 |
|
Maximum inclination angle of front wheels |
° |
±17 |
||
Maximum swing angle of front axle |
° |
±15 |
||
Maximum swing angle of balance box |
° |
front 15, rear 15 |
||
Maximum steering angle of frame |
° |
±25 |
||
Maximum turning radius |
m |
7.3 |
||
Blade |
Maximum lifting height |
mm |
480 |
|
Maximum shoveling depth |
mm |
715 |
||
Maximum lateral inclination angle |
° |
90 |
||
Cutting angle |
° |
29-69 |
||
Oil filling amount |
Slewing angle |
° |
360 |
|
Length x chord height |
mm |
3965 x 610 |
||
Coolant |
L |
50 |
||
Fuel tank |
L |
270 |
||
Engine |
L |
24 |
||
Transmission |
L |
38 |
||
Balance box |
L |
60 |
||
Drive axle |
L |
36 |
||
Hydraulic oil |
L |
190 |
