FOB Price: $10000.00-$1000000.00
View All >
Model: XSL7/360
Engine: YUCHAI
After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
XCMG factory 700m deep water well drilling rig machine XSL7/360

Content:

Or choose from these questions:
What is the best price you can offer?
Do you support customization?
What is the MOQ for this product?

*Email:

Full Name:

Mobile phone:

XSL7/360
Specs & Compare
Details
Specs & Compare
Select 3 models for comparison
Certification
Dimension(L*W*H)
Weight
Power(W)
Voltage
Usage
Model Number
Brand Name
Place of Origin
Power Type
Type
Engineering & Construction Machinery
XSL7/360
CE/ISO9001
5390*2500*2880mm
135000kg
154kW
--
Water Well
XSL7/360
XCMG
Jiangsu,China
Diesel
Deep Water Well Drilling Rig
+   Add a Product
+   Add a Product

Summary

  • Certification:CE/ISO9001
  • Dimension(L*W*H):5390*2500*2880mm
  • Weight:135000kg
  • Power(W):154kW
  • Usage:Water Well
  • Model Number:XSL7/360
  • Brand Name:XCMG
  • Place of Origin:Jiangsu,China
  • Power Type:Diesel
  • Type:Deep Water Well Drilling Rig

Specifications

  • Weight:135000.000kg
  • Condition:New
  • Moving Type:Other
  • Drilling depth:700m
  • Max. lifting capacity:360kN
  • Max. feeding capacity:150kN
  • Max. lifting speed:32m/min
  • Max. torque:14500/72N.m
  • Hoisting capacity:15kN

Packaging & Shipping

  • Delivery Lead Time:7 days for ready goods
  • Minimum Order:1 Piece
  • Supply Ability:10,000 Set/ Sets per Month
  • Total Quantity In Stock:Over 5000
  • Delivery Port:Any Port In China

XCMG factory 700m deep water well drilling rig machine XSL7/360

XCMG 700m deep water well drilling rig machine XSL7/360.



XSL series deep water well drilling rig uses full hydraulic control and the top drive to drive the rotation of drilling tools with very high drilling efficiency. Reasonable overall layout uses the tractor-mounted or all terrain chassis for transportation.



Very flexible in difficult roads, it can be widely used in many fields such as resource exploration of hydrology wells, coalbed methane, shallow layer of shale gas, terrestrial heat, etc., and can also be used for coal-mine gas exploitation or salvage work.



The top-mounted driving head principal shaft has a great drift diameter, which is suitable for many kinds of construction work such as slurry drilling, air drilling, and air foam drilling, meeting the demands of well-drilling in different terrain strata.



Performance Characteristics:



* Mature and reliable hydraulic top drive power head with large bearing capacity and good sealing effect.



* The gap adjustable telescopic drill collar can meet the requirements of long casing construction and has high work efficiency.



* Unique hydraulic matching technology for high system efficiency.



* Integrated visualization pressurizes and pressurize decompression feed system for fine adjustment of drilling pressure according to drilling depth.



* Four hydraulic high supporting legs are provided to achieve rapid leveling of the rig without lifting.





* The swing-type centering device provides a wide working space when working.

XCMG factory 700m deep water well drilling rig machine XSL7/360

Parameter

Unit

XSL7/360

Drilling capability

Drilling depth

m

700(φ102)

Max. diameter of working floor

mm

φ500

Feeding system

Max. lifting capacity

kN

360

Max. feeding capacity

kN

150

Max. lifting speed

m/min

32

Max. feeding speed

m/min

60

Stroke

mm

7000

Top drive

Max. torque

N.m

14500/7250

Max. speed

r/min

150/75

I.D

mm

φ55

Deck engine

Type



YC6J210-T300

Rated power

kW

154

Tool winch

Hoisting capacity

kN

15

Breakout device

Max. breakout torque

N.m

32000

Mud pipe

I.D

mm

φ55

Max. pressure

MPa

8

Chassis

Highest speed

km/h

3

Max. climbing gradient

%

39

Max. ground clearance of crawler

mm

1320

Max. inner distance between front support legs

mm

3020

Max. iner dstance between back support legs

mm

2840

Working dimension

mm

4850*2840*9900

Transportation dimension

mm

5390*2500*2880

Weight

t

13.5
