XCMG official 2m cold planer machine XM200E mini road milling machine lathe with parts for sale
Summary
- Dimension(L*W*H):6750*2500*2900mm
- Weight:28500kg
- Power(W):353kW
- Model Number:XM200E
- Brand Name:XCMG
- Place of Origin:Xuzhou, Jiangsu, China
- Milling width (mm):2000mm
- Milling depth (mm):300mm
- Certification:CE/ISO9001
Specifications
- Weight:28500.000kg
- Condition:New
- Moving Type:Other
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
2m cold planer machine XM200E mini road milling machine
lathe with parts.
XCMG XM200E road milling machine is the maintenance
construction machinery of asphalt concrete pavement, mainly used for excavation
and renovation of highway, urban road, airport, freight yard, parking lot and
other large area of asphalt concrete pavement.
The equipment features advanced performance, high
efficiency, simple process, easy control of milling depth, flexible operation,
good maneuverability and the old material recycling and utilization. It is an
ideal equipment for pavement maintenance and renovation.
Performance and characteristic:
1.Hydraulic driving milling drum has the obvious
characteristics of stable milling and high efficiency.
2.Compact three-wheeled machine with front-wheel drive.
3.The high-strength and high wear resistance imported
cutter head and cutter rest have long service life and low construction cost.
4.The imported hydraulic elements have high working
reliability.
5.Hydraulic handheld breakers and rumble strip equipment
can be selected.
|
Model |
Unit |
XM200E |
|
|
Max. milling with |
mm |
2000 |
|
|
Max. milling depth |
mm |
300 |
|
|
Milling wheel |
Number of tools |
162 |
|
|
Drum diameter with tools |
mm |
980 |
|
|
Engine |
Model |
DHP12 |
|
|
Rated power |
kW |
353 |
|
|
Rated speed |
rpm |
2100 |
|
|
Specifications |
Operating speed |
m/min |
0~34 |
|
Travel speed |
km/h |
0~5 |
|
|
Ground clearance |
% |
80 |
|
|
Ground clearance |
mm |
≤320 |
|
|
Operating weight |
kg |
28500 |
|
|
Volume |
Fuel tank |
L |
800 |
|
Hydraulic oil tank |
L |
300 |
|
|
Water tank |
L |
2300 |
|
|
Conveyor |
Width |
mm |
800 |
|
Measurement |
Overall machinery LxWxH |
mm |
6750×2500×2900 |
|
Conveyor LxWxH |
mm |
8000×1150×900 |
|
|
Travel mode |
Track |
||
