XCMG 2m road cold planer milling machine XM200 china mini asphalt milling machine price for sale
Summary
- Weight:34000kg
- Power(W):390kw
- Model Number:XM200
- Brand Name:XCMG
- Place of Origin:Jiangsu,China
- Milling width (mm):2m
- Milling depth (mm):320mm
- Certification:CE/ISO9001
Specifications
- Weight:34000.000kg
- Condition:New
- Moving Type:Other
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
2m road cold planer milling machine XM200 china mini
asphalt milling machine.
The XM200 is mainly used for maintenance renovation of
large-scale asphalt concrete pavement, fine cutting of cement road surface and
surface layer milling, cement stabilized soil layer renovation. XM200 is a high
efficient economic type milling machine.
Performance Characteristics:
1.The anti-torsion chassis is made of high strength
material and steel plates, can resist deformation under various load and
terrain conditions.
2.Four crawlers are independently driven by hydraulic
motors. All speed regulation can be operated on the control console at both
sides of the driver.
3.The power of diesel engine is transmitted through the
clutch and power conveyor belt to the reducer of milling rotor, in order to
provide the biggest milling power
4.The milling machine is equipped with a set of accurate
automatic vertical control device to control the milling depth.
|
Item |
Unit |
XM200 |
|
|
Maximum milling width |
mm |
2000 |
|
|
Maximum milling depth |
mm |
320 |
|
|
Milling wheel |
Tool spacing |
mm |
15 |
|
Number of
tools |
162 |
||
|
Milling wheel diameter (with tool) |
mm |
980 |
|
|
Milling wheel
maximum inclination |
° |
5 |
|
|
Diesel engines |
Cooling method |
Water cooling |
|
|
Model |
DHP13 |
||
|
Number of cylinders |
6 |
||
|
Rated power |
kw |
390 |
|
|
Engine speed |
rpm |
2100 |
|
|
Fuel
consumption: full load |
l/h |
103 |
|
|
Speed/grade ability |
Working speed |
m/min |
0-34 |
|
Walking speed |
km/h |
0-5 |
|
|
Theoretical Gradeability (Working Blocks) |
% |
60% |
|
|
Ground
clearance |
320 |
||
|
Weight / load |
Shipping weight |
kg |
30000 |
|
Working weight |
kg |
34000 |
|
|
Track device |
Front track |
mm |
1720×300×620 |
|
Rear crawler |
mm |
1720×300×620 |
|
|
Box volume |
Fuel tank |
L |
1400 |
|
Hydraulic tank |
L |
400 |
|
|
Water tank |
L |
3400 |
|
|
Electrical
system |
V |
24 |
|
|
Conveyor belt device |
Aggregate conveyor belt width |
mm |
800 |
|
Discharging
conveyor width |
mm |
800 |
|
|
Conveyor belt conveying capacity |
≤m3/h |
330 |
|
|
Shipping dimensions |
Machinery
(length×width×height) |
mm |
7650×2580×3000 |
|
Belt conveyor (length × width × height) |
mm |
8060×1150×1500 |
|
