XCMG official manufacturer 24m self propelled telescopic boom lift XGS24 hydraulic mobile elevated work platform price for sale
![](/app/topc/statics/images/close.png)
![XCMG official manufacturer 24m self propelled telescopic boom lift XGS24 hydraulic mobile elevated work platform price for sale](http://www.machmall.com/images/store/357636/item/XGS24-1.jpg)
![](/app/topc/statics/images/close.png)
Summary
- Weight:12500kg
- Overall Dimension:10150*2490*2800mm
- Table Size:2400*900mm
- Max Lifting Height:24m
- Min Lifting Height:2.8m
- Rated Loading Capacity:340kg
- Lift Drive / Actuation:Hydraulic
- Lift Mechanism:Telescoping Lift
- Model Number:XGS24
- Brand Name:XCMG
- Place of Origin:China
- Certification:ISO
Specifications
- weight:12500.000kg
- Condition:New
- Moving Type:Other
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
24m self
propelled telescopic boom lift hydraulic mobile elevated work platform price
for sale XGS24.
XGS24 self-propelled Telescopic Mobile Elevating Work
Platform highlights with outstanding performance, efficiency, dynamics and easy
operation. It is leading in the industry with maximum carrying capacity of
340kg, high operation height and amplitude, suit for construction of large load
and wide operation area.
Advantages and features:
* Dual parallel linkage and telescopic arm could realize
the dynamic adjustment of vehicle center of gravity, making the complete
vehicle more stable.
* With 4WD, off-road wide tires and axle balance system,
the machine is excellent in drive and adaptability to road.
* Multi-load envelope control technologies could
real-time monitor the load, effectively making use of boom and making its work
performance at leading edge.
* Auto balance extending mechanism improves safety of
extending mechanism and extends service life of steel rope.
* Electrical control system adopts the distributed
control technologies based on PLC and CAN, implementing the auto leveling, the
weighting of platform payload, the dynamic monitoring and the fault warning.
Item |
Unit |
Parameter |
Overall length of complete machine |
mm |
10150 |
Overall width of complete machine |
mm |
2490 |
Overall height |
mm |
2800 |
Wheelbase |
mm |
2500 |
Max. working height |
m |
24 |
Max. platform height |
m |
22 |
Max. working range |
m |
18.3 |
Max. load capacity |
kg |
230
(unrestricted)/340 (restricted) |
Luffing range of boom |
° |
-5 ~ +75 |
Slewing angle of turntable |
° |
360 |
Max. tail swing |
mm |
1550 |
Dimension of platform |
mm |
2400×900 |
Slewing angle of platform |
° |
160 |
Overall weight |
kg |
12500 |
Max. traveling speed |
km/h |
6 |
Min. turning radius |
m |
6 |
Min. ground clearance |
mm |
230 |
Max. gradeability |
% |
45 |
Specification of tire |
- |
Solid tire 36×14-20/7.5 Or Foam tire 355/55D625 |
Engine model |
- |
Perkins
404D-22T |
Engine rated power |
kW/(r/min) |
43/(2600) |
