XCMG official 500 ton construction machine xcmg crawler crane XGC500 for sale
Summary
- Model Number:XGC500
- Brand Name:XCMG
- Place of Origin:Jiangsu,China
- Rated Lifting Moment:6276t.m
- Rated Loading Capacity:500t
- Application:construction
- Certification:CE/ISO9001
Specifications
- Weight:500000.000kg
- Condition:New
- Moving Type:Crawler
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG official 500 ton construction machine xcmg crawler crane XGC500.
* Perfect self-assembly/disassembly functions can achieve self- assembly/ disassembly for track frame, turntable counterweight, and boom base.
* Luffing system integrated transport. 4-piece luffing system integrated transport of mast main luffing system, super-lift mast luffing system, and tower jib.
* Use of particular pendant connection design to make pendant assembly/ disassembly more convenient. Meanwhile pendant can be transported with boom sections, to save boom transition time.
* All counterweights on the same platform products have the unified specifications, truly realize common use and interchangeability for the parts.
* Sprocket-style travel with good coupling engagement; 4-drive reducer for front/rear drive unit, improve the whole vehicle travel, steering and climbing ability.
* For the demand of wind power installation and maintenance, wind power jib can meet the 2.0~2.5 MW below wind turbine lifting demand.
Item |
Unit |
Specification |
||
Max. rated lifting capacity |
Standard working condition |
Heavy-duty main boom |
t |
450 |
|
|
Light-duty main boom |
t |
230 |
|
|
Tower-type auxiliary boom |
t |
216 |
|
|
Wind power goose-head boom |
t |
116 |
|
Super-lifting working condition |
Heavy-duty main boom |
t |
500 |
|
|
Light-duty main boom |
t |
230 |
|
|
Tower-type auxiliary boom |
t |
230 |
Max. lifting torque |
Standard working condition |
Heavy-duty main boom |
t.m |
373.3*8=2986 |
|
Super-lifting working condition |
Heavy-duty main boom |
t.m |
391.7*16=6267 |
Dimension parameters |
Length of main boom |
m |
24~96 |
|
|
Luffing angle of main boom |
° |
-3~85° |
|
|
Length of tower-type auxiliary boom |
m |
24~84 |
|
|
Length of wind power goose-head boom |
m |
7 |
|
Speed parameter |
Max. single rope speed of hoisting mechanism (non-load, sixth layer) |
m/min |
130 |
|
|
Max. single rope speed of main boom luffing mechanism (First Layer) |
m/min |
2×53 |
|
|
Max. slewing speed |
r/min |
1 |
|
|
Max. traveling speed |
km/h |
0.73 |
|
Gradeability |
|
30% |
||
Average ground pressure |
MPa |
0.132 |
||
Engine power |
kW |
360 |
||
Overall weight (24m heavy-duty main boom, 500t hook) |
t |
375 |
||
Max. Mass of Single Piece in Transport State |
t |
49 |
||
Max. dimensions of singe piece (slewing table) in transport state (L × W × H) |
m |
11.5×3.4×3.4 |
