XCMG Manufacturer XGC200 200 Ton Crawler Crane Price
.jpg)
Summary
- Model Number: XGC200
- Brand Name:XCMG
- Place of Origin:Jiangsu,China
- Rated Lifting Moment:1043.8t.m
- Rated Loading Capacity:200t
- Application:construction
- Certification:CE/ISO9001
Specifications
- Weight:176000.000kg
- Condition:New
- Moving Type:Crawler
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG Manufacturer XGC200 200 Ton Crawler Crane.
Performance Characteristics:
1. High lifting performance
Boom max. lifting capacity/radius 180t/5m, boom max. load moment 1043.8tm. Boom max. length luffing jib max. length 58m+41m, luffing jib max. lifting capacity 50t.Fixed jib max. lifting capacity 33.5t.
2. Optimized design of transport and assembly/ disassembly
* Fully equipped self-assembly/disassembly system (Optional) can easily achieve: rear counterweight self-assembly/disassembly, track frame self-assembly/disassembly, and boom base self-assembly/disassembly.
* Largest single unit transport weight is controlled within 30t, transport width not more than 3m, so as to meet the transport requirement of global accessibility.
* Fixed jib can be three-piece integrated transport, and transport design of inserted boom sections, maximize the use of transport space, and save transport costs.
3. More optimized structural design
* Superstructure is a large box-type structural design, with heavy load bearing capacity, light weight, and good rigidity.
* Auxiliary hoisting winch is placed in boom base, with relaxed arrangement for turntable, easy maintenance.
.jpg)
|
Parameter Item |
Unit |
Parameter value |
|
Operation performance parameter |
|
* |
|
Max. rated lifting capacity for boom |
(t) |
200 |
|
Max. rated lifting capacity for fixed jib |
(t) |
33.5 |
|
Max. rated lifting capacity for luffing jib |
(t) |
50 |
|
Max. load moment |
(t.m) |
1043.8 |
|
Max. rated lifting capacity for tower jib |
(t) |
50 |
|
Boom length |
(m) |
19~82 |
|
Boom luffing angle |
(°) |
30~83 |
|
Fixed jib length |
(m) |
13~31 |
|
Tower jib length |
(m) |
20~59 |
|
Max. dimension of single unit in transport state (L×W×H) |
(m) |
9.58×3.0×3.3 |
|
Fixed jib offset angle |
(°) |
15,30 |
|
Max. single line speed for hoist mechanism |
(m/min) |
120 |
|
Max. single line speed for boom luffing mechanism |
(m/min) |
2×34 |
|
Max. single line speed for jib luffing mechanism |
(m/min) |
41.6 |
|
Max. slewing speed |
(m/min) |
1.5 |
|
Max. travel speed |
(m/min) |
1.3 |
|
Grade ability |
(%) |
30 |
|
Mean ground pressure |
(MPa) |
0.112 |
|
Max. single line speed for towerjib luffing mechanism |
(m/min) |
41.6 |
|
Model |
|
SC9D |
|
Engine power |
(kW) |
243 |
|
Emission |
|
National III |
|
Overall crane mass |
(t) |
176(main hook, allcounterweights, 19m boom) |
|
Max. mass of the single unit in transport state |
(t) |
30 |
