XCMG Official XGA5902D3T China New Truck Dumper 90 ton Off Road Tipper Truck Dumper For Sale
.jpg)
Specifications
- Weight:32000.000kg
- Condition:New
- Moving Type:Wheel
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG Official XGA5902D3T China New Truck Dumper 90 ton Off
Road Tipper Truck Dumper.
*
According to each of the engine torque characteristic curve, perfectly match
the different types of Fast manual gearbox, Allision automatic gearbox, to
protect the most energy rationalization output, the vehicle has an excellent
starting ability, climbing ability.
*
Optimized arrangement of the traditional system architecture, reducing the loss
of energy transfer process to ensure the kinetic energy efficient, rapid
transmission.
*
Using the unique steering and steering follower, the steering mechanism.
Steering light, the failure rate lower.
*
Dual-circuit brake system equipped with high pressure geography accumulator volume
increases, the brake pressure increasing 25% to 1 Mpa, shorten braking
distance.
|
Vehicle model |
XGA5902D3T |
||
|
Mass parameter |
Curb weight |
32000kg |
|
|
GVW |
90000kg |
||
|
Performance |
Max. speed |
48km/h |
|
|
Min. turning diameter |
9.9m |
||
|
Grade ability |
39% |
||
|
Fuel tank |
500L |
||
|
Dimensions |
Overall dimensions |
Length |
9045mm |
|
Width |
3400mm |
||
|
Height |
3972mm |
||
|
Wheelbase |
3800+1600mm |
||
|
Wheel track |
Front tire |
2800mm |
|
|
Rear tire |
2526mm |
||
|
Min.clearance |
380mm |
||
|
Approach angle |
36° |
||
|
Departure angle |
45° |
||
|
Front overhang |
1755mm |
||
|
Rear overhang |
1890mm |
||
|
Cargo size |
6000×3200×1600mm |
||
|
Cab |
Model |
K20 HANWO P9 RHD |
|
|
Passengers |
1 |
||
|
Engine |
Model |
WP12G460E310 |
|
|
Displacement |
11.596L |
||
|
Output power |
338kW |
||
|
Max. torque speed |
2000N·m) |
||
|
Clutch |
Model |
Φ430 Pull type diaphragm spring clutch |
|
|
Operation |
Hydraulic manual |
||
|
Transmission |
Model |
8DS240A |
|
|
PTO |
QH70 |
||
|
Operation |
Flexible shaft |
||
|
Forward ratio |
8.15/6.01/4.11/3.05/2.12/1.45/1.00/0.76 |
||
|
Reverse ratio |
7.57 |
||
|
Driven axle |
Model |
35T PENGXIANG |
|
|
Main reducer ratio |
15.66 |
||
|
Brake type |
Drum |
||
|
Differential lock |
Inter-axle differential lock |
||
|
Front axle |
Model |
19T PENGXIANG |
|
|
Brake type |
Drum |
||
|
车轮 /Wheel |
轮辋/Rim |
10.00W-24 |
|
|
轮胎/Tire |
14.00-25NHS |
||
|
车架 /Frame |
型式/Model |
厢型梁/Box beam |
|
|
主纵梁截面/HxW-t |
450mm |
||
|
车架总成宽度/Frame width |
1060mm |
||
|
悬架/Suspension |
前/Front |
型式/Type |
钢板弹簧/Leaf spring |
|
板簧片数 /Leaf springs |
15 |
||
|
后/Rear |
型式/Type |
平衡悬架/Balanced suspension |
|
|
板簧片数 /Leaf springs |
15 |
||
|
转向系/Steering |
转向器型式/Model |
Φ120/循环球式液压助力 /Circulating ball type hydraulic power |
|
|
转向器速比/Steering Ration |
23.04 |
||
|
转向油泵最大压力 /Max pressure of pump |
17MPa |
||
|
制动系 /Brake System |
额定工作压力/Rated pressure |
1MPa |
|
|
行车制动系型式 /Service brake system |
双回路气压制动 /Dual circuit pneumatic braking |
||
|
驻车制动系型式 /Parking brake system |
弹簧储能断气制动 /Spring energy storage air brake |
||
|
辅助制动型式 /Auxiliary braking system |
发动机排气制动+缓速器 /Engine exhaust brake+Retarder |
||
|
电器系统/Electrical system |
电压/Voltage |
24V |
|
|
发电机功率/Generator power |
2.2Kw |
||
|
蓄电池电压/电容 /Battery voltage/capacitance |
2×12V/165Ah |
||
