XCMG Official Tipper Truck Dumper 47 Ton XGA5470D3TQ 6*6 Dumper For Sale

View All >

Model： XGA5470D3TQ

After-sales Service： Engineers available to service machinery overseas

Min Order Quantity： 1 Unit

Delivery Time：

In Stock (Within 7 days)

Production (Within15 to 20 days)

Customization (negociated delivery time)

After-sales Service：

1. It is recommended that you keep in touch with the seller after purchasing offline...

About after-sales service:

1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:

1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.

Inquiry Chat Now

Favorite Products

Product:

XCMG Official Tipper Truck Dumper 47 Ton XGA5470D3TQ 6*6 Dumper For Sale

Quantity:

- + /EA

Content:

Or choose from these questions:

What is the best price you can offer?

Do you support customization?

What is the MOQ for this product?

*Email:

Full Name:

Mobile phone:

XGA5470D3TQ

Specs & Compare

Details

Specifications

Weight:19000.000kg
Condition:New
Moving Type:Wheel

Packaging & Shipping

Delivery Lead Time:7 days for ready goods
Minimum Order:1 Piece
Supply Ability:10,000 Set/ Sets per Month
Total Quantity In Stock:Over 5000
Delivery Port:Any Port In China

XCMG Official Tipper Truck Dumper 47 Ton XGA5470D3TQ 6*6 Dumper For Sale

XCMG Official Tipper Truck Dumper 47 Ton XGA5470D3TQ 6*6 Dumper.

* According to each of the engine torque characteristic curve, perfectly match the different types of Fast manual gearbox, Allision automatic gearbox, to protect the most energy rationalization output, the vehicle has an excellent starting ability, climbing ability.

* Optimized arrangement of the traditional system architecture, reducing the loss of energy transfer process to ensure the kinetic energy efficient, rapid transmission.

* Using the unique steering and steering follower, the steering mechanism. Steering light, the failure rate lower.

* Dual-circuit brake system equipped with high pressure geography accumulator volume increases, the brake pressure increasing 25% to 1 Mpa, shorten braking distance.

XCMG Official Tipper Truck Dumper 47 Ton XGA5470D3TQ 6*6 Dumper For Sale

	Vehicle model		XGA5470D3TQ
Mass parameter	GVW		19000 kg
	GCW		47000 kg
Performance	Drive form		6×6
	Max. speed		65 km/h
	Min. turning diameter		9.4 m
	Grade ability		60%
	Fuel tank		300 L
Dimensions	Overall dimensions	Length	8755 mm
		Width	2600 mm
		Height	3650 mm
	Wheelbase		4000+1400mm
	Wheel track	Front tire	2025mm
		Rear tire	1868mm
	Min.Clearance		380
	Approach angle		23°
	Departure angle		36°
	Front overhang		1460mm
	Rear overhang		1895mm
	Cargo size		5800×2400×1500mm
Cab	Model		2.5m Left dislocation cab
	Passengers		1
Engine	Model		WP10.340E32
	Displacement		9.726L
	v		250kW
	torque/speed		1250N·m
Clutch	Model		Φ430 Pull type diaphragm spring clutch
	Operation		Hydraulic manual
Transmission	Model		9JSD150
	PTO		QH50
	Operation		Flexible shaft
	Forward ratio		12.51/8.39/6.15/4.59/3.40/2.47/1.81/1.35/1.00
	Reverse ratio		13.41
Driven axle	Model		16T HANDE
	Main reducer ratio		6.733
	Brake type		Drum
	Differential lock		Inter-axle differential lock
Front axle	Model		9.5T HANDE
	Brake type		Drum
Wheel	Rim		8.5V-20
	Tire		12.00R20
Frame	Model		Groove straight beam
	HxW-t		320mm
	Frame width		865mm
Suspension	Front	Type	Leaf spring
		Leaf springs	10
	Rear	Type	Balanced suspension
		Leaf springs	13
Steering	Model		Φ120/ Circulating ball type hydraulic power
	Steering Ration		23.27
	Max pressure of pump		15MPa
Brake System	Rated pressure		1MPa
	Service brake system		Dual circuit pneumatic braking
	Parking brake system		Spring energy storage air brake
	Auxiliary braking system		Engine exhaust brake+Retarder
Electrical system	Line type		Two wire system, power control positive
	Voltage		24 V
	Generator power		2.2Kw
	Battery voltage/capacitance		2×12V/165Ah
