XCMG official scissor lift platform 10m XG1012HD hydraulic lifting table price
Summary
- Weight:2620kg
- Overall Dimension:2477*1190*2355mm
- Table Size:2277*1120mm
- Max Lifting Height:10m
- Rated Loading Capacity:450kg
- Power:4.5kw
- Lift Drive / Actuation:Hydraulic
- Lift Mechanism:Scissor Lift
- Model Number:XG1012HD
- Brand Name:XCMG
- Place of Origin:Xuzhou, Jiangsu, China
- Certification:CE/ISO9001
Specifications
- Weight:2620.000kg
- Condition:New
- Moving Type:Other
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG official scissor lift platform 10m XG1012HD
hydraulic lifting table.
New XG1012HD scissor lifting table developed by XCMG has
the work height at 10m, the vehicle width at 1.19m, the rated load at 450kg,
max. gradeability at 25%.
This kind of platforms are widely applied to warehouses,
factories, airports, and train stations, especially the narrow work sites.
Advantages and features:
1.Effective and energy-saving electric-drive system
features zero emission and low noise.
2.Features compact structure, advanced performance,
completed safety devices.
3.Meeting the customer needing for safety, reliability
and intelligence.
4."Zero Turning Radius "is unique and enable
machine to corner in narrow room.
5.Max. payload at 450kg, leading the industry. Maximum
traveling speed 3.2km/h and 25% gradeability make the driving easier.
|
Item |
Unit |
Parameter |
|
Dimension of machine Length (without ladder) |
mm |
2477(2267) |
|
Dimension of machine Width |
mm |
1190 |
|
Dimension of machine Height (platform folded) |
mm |
2355(1805) |
|
Wheelbase |
mm |
1877 |
|
Min. ground clearance |
mm |
100/20 |
|
Max. height of platform |
m |
8 |
|
Max. working height |
m |
10 |
|
Minimum turning radius (inner wheel/outer wheel) |
m |
0/2.3 |
|
Rated load |
kg |
450 |
|
Payload of extended platform |
kg |
115 |
|
Lifting time |
s |
29-40 |
|
Lowering time |
s |
34-45 |
|
Drive speed(lowered) |
km/h |
3.2 |
|
Drive speed(elevated) |
km/h |
0.8 |
|
Max. gradeability |
% |
25 |
|
Tilt warning angle (side/forward and backward) |
° |
1.5/3 |
|
Lifting /traveling motor Model |
- |
- |
|
Lifting /traveling motor Rated power |
kW |
3.3 |
|
Lifting /traveling motor Manufacturer |
- |
- |
|
Battery |
v/Ah |
4x6/225 |
|
Tire models |
- |
Traceless and solid/381×127 |
