XCMG 6m hydrolic scissor arial platform lift electric XG0607DC
Summary
- Weight:915kg
- Overall Dimension:1440*760*2020mm
- Table Size:1290*700mm
- Max Lifting Height:5.6m
- Min Lifting Height:2.0m
- Rated Loading Capacity:240kg
- Lift Drive / Actuation:Electric
- Lift Mechanism:Scissor Lift
- Model Number:XG0607DC
- Brand Name:XCMG
- Place of Origin:Xuzhou, Jiangsu, China
- Certification:CE/ISO9001
Specifications
- Weight:915.000kg
- Condition:New
- Moving Type:Other
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG 6m hydrolic scissor arial platform lift electric
XG0607DC.
New scissor electric platform lift XG0607DC developed by
XCMG has the work height at 5.6m, the vehicle width at 0.76m, the rated load at
240kg, platform extend length at 0.6m and maximum gradeability at 25%. This vehicle features compact structure,
advanced performance, completed safety devices, especially suitable for
construction.
In addition. It is free of any pollution, with steady
lifting / lowering, easy control and maintenance. Therefore, this kind of
platforms are widely applied to warehouses, factories, airports, and train
stations, especially the narrow work sites.
Advantages and features：
1.Effective and energy-saving electric-drive system
features zero emission and low noise.
2.Meeting the customer needing for safety, reliability
and intelligence.
3.Narrow- structure design enables the complete vehicle
to easily pass through a single gateway.
4.foldable fence could make the transportation easier.
5.“Zero Turning Radius” is unique and enable machine to
corner in narrow room.
6.Maximum payload at 240kg, leading the industry. Maximum
traveling speed 4km/h and 25% gradeability make the driving easier.
|
Item |
Unit |
XG0607DC |
|
Dimension of machine (LxWxH) |
mm |
1440x760x2020 |
|
Wheelbase |
mm |
1030 |
|
Wheel track |
mm |
684 |
|
Minimum ground clearance (Pit protector ascending/descending) |
mm |
65/15 |
|
Dimension of working platform (LxWxH) |
mm |
1290x700x600 |
|
Total mass of machine |
kg |
915 |
|
Max. height of platform |
m |
3.6 |
|
Min. height of platform |
m |
0.9 |
|
Maximum working height |
m |
5.6 |
|
Minimum turning radius (inner wheel/outer wheel) |
m |
0.4/1.55 |
|
Rated load of working platform |
kg |
240 |
|
Payload after work platform extended |
kg |
100 |
|
Lifting time of working platform |
s |
32 |
|
Lowering time of working platform |
s |
23 |
|
Max. running speed at low position. |
km/h |
4.0 |
|
Max. traveling speed at high altitude |
km/h |
0.5 |
|
Maximum gradeability |
% |
25 |
|
Battery Voltage |
v |
24 |
|
Battery Capacity |
Ah |
85 |
|
Battery Manufacturer |
— |
Fullriver |
