XCMG 7 ton excavator XE75D china mini hydraulic crawler excavator construction equipment price
Summary
- Rated Speed:4.2km/h
- Max Digging Radius:6260mm
- Machine Weight:7460kg
- Maximum Digging Depth:4020mm
- Maximum Digging Height:7085mm
- Bucket capacity:0.3m3
- Operating Weight:7460Kg
- Model Number:XE75D
- Brand Name:XCMG
- Place of Origin:Jiangsu,China
Specifications
- Weight:7460.000kg
- Condition:New
- Moving Type:Other
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
7 ton excavator XE75D china mini hydraulic crawler
excavator construction equipment.
* Equipped with Famous engine that meets the Tier III
emission requirement.
* The cab is equipped with large high-strength stalinite,
which provides wide view.
* Reinforced boom, arm and bucket to ensure powerful
digging force in harsh conditions.
* Full open hood is easy to troubleshoot the engine and
other parts.
* Optional break hammer and pipeline, quick coupler,
rotary driller, hydraulic vibrating tamper are available.
* The highest breakout force on the loading end is
leading the industry by 15%~20% compared with like models.
* The advanced structure and hinge points on the digging
end and the industry’s largest rotating angle of the bucket ensure strong soil
holding capacity.
|
Description |
Unit |
Parameter value |
|
|
Operating weight |
Kg |
7460 |
|
|
Bucket capacity |
m³ |
0.3 |
|
|
Engine |
Model |
/ |
V2607-DI-TE3B |
|
No. of
cylinders |
/ |
4 |
|
|
Output power |
kw/rpm |
43/2000 |
|
|
torque/speed |
N.m |
225.8/1400-1800 |
|
|
Displacement |
L |
2.615 |
|
|
Main performance |
Travel
speed(H/L) |
km/h |
5.4/2.9 |
|
Rotating speed |
r/min |
10 |
|
|
Gradeability |
° |
35 |
|
|
Ground pressure |
kPa |
33.5 |
|
|
Bucket digging
force |
kN |
57 |
|
|
Arm crowd force |
kN |
38 |
|
|
Maximum
traction |
kN |
68.3 |
|
|
Hydraulic system |
Rated flow of main pump |
L/min |
160 |
|
Pressure of
prime valve |
MPa |
28 |
|
|
Pressure of travel system |
MPa |
27.4 |
|
|
Pressure of
swing system |
MPa |
20.6 |
|
|
Pressure of pilot system |
MPa |
3.5 |
|
|
Oil Capacity |
Fuel tank
capacity |
L |
130 |
|
Hydraulic tank capacity |
L |
76 |
|
|
Engine oil
capacity |
L |
10 |
|
|
Appearance size |
Overall length |
mm |
6150 |
|
Overall width |
mm |
2230 |
|
|
Overall height |
mm |
2685 |
|
|
Width of
platform |
mm |
2070 |
|
|
Length of crawler |
mm |
2200 |
|
|
Overall width
of chassis |
mm |
450 |
|
|
Width of crawler |
mm |
2195 |
|
|
Length of
wheel |
mm |
1750 |
|
|
Crawler gauge |
mm |
6150 |
|
|
Clearance
under counterweight |
mm |
815 |
|
|
Min. ground clearance |
mm |
380 |
|
|
Dozer blade
width/height |
mm |
2200/396 |
|
|
Working scope |
Max. digging height |
mm |
7085 |
|
Max. dumping
height |
mm |
5160 |
|
|
Max. digging depth |
mm |
4020 |
|
|
Max. vertical
wall digging depth |
mm |
2920 |
|
|
Max. digging reach |
mm |
6260 |
|
|
Min. swing
radius |
mm |
1818 |
|
|
Min. tail swing radius |
mm |
1800 |
|
|
Max.dozer
blade hoist height |
mm |
363 |
|
|
Max. dozer blade digging depth |
mm |
346 |
|
