XCMG Official 5 Ton Mini Excavators XE55E China New Small Crawler Excavator With CE For Sale
Summary
- Rated Speed:9.5 r/min
- Max Digging Radius:6110mm
- Machine Weight:5700kg
- Maximum Digging Depth:3640mm
- Maximum Digging Height:5650Kg
- Bucket capacity:0.16mmm
- Operating Weight: 5.5 tons
- Model Number:XE55E
- Brand Name:XCMG
- Place of Origin:Jiangsu, China
Specifications
- Weight:5700.000kg
- Condition:New
- Moving Type:Other
- Type:Mini excavator
- Engine :Kubota
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG Official 5 ton Mini Excavators XE55E China New Small Crawler Excavator with CE for Sale.
1.Engine that meets Euro V emission standards is highly reliable, environmentally friendly, and have lower fuel consumption.
2.Compact and Tailless design cooperates with boom swing function, which can adapt to the narrow space operation flexibly.
3.A set of high-pressure quick-change pipelines and two sets of flow-adjustable backup circuit can truly realize one machine with multiple functions.
4.Key electrical elements are arranged in new type electrical box, which makes daily maintenance more convenient.
|
Item |
Unit |
Parameters |
|
|
Model |
Operating weight |
Kg |
5700 |
|
Bucket capacity |
m³ |
0.16 |
|
|
Engine |
Model |
- |
Kubota V2403 |
|
No. of cylinders |
- |
4 |
|
|
Rated power |
kw/rpm |
31.2/2200 |
|
|
Maximum torque/speed |
N.m |
159.8/1500 |
|
|
Displacement |
L |
2.434 |
|
|
Main performance |
Travel speed (H/L) |
km/h |
4.6/2.8 |
|
Swing speed |
r/min |
9.5 |
|
|
Gradeability |
° |
≤35 |
|
|
Ground pressure |
kPa |
32.0 |
|
|
Bucket digging force |
kN |
44.5 |
|
|
Arm digging force |
kN |
29.2 |
|
|
Maximum tractive force |
kN |
52.8 |
|
|
Hydraulic system |
Rated flow of main pump |
L/min |
158.4 |
|
Main safety valve pressure |
Mpa |
30 |
|
|
Travel system pressure |
Mpa |
30 |
|
|
Swing system pressure |
Mpa |
24 |
|
|
Pilot system pressure |
Mpa |
3.5 |
|
|
Oil capacity |
Fuel tank capacity |
L |
68 |
|
Hydraulic tank capacity |
L |
46 |
|
|
Engine oil capacity |
L |
9.5 |
|
|
Appearance size |
A Overall length |
mm |
5340 |
|
B Overall width |
mm |
1960 |
|
|
C Overall height |
mm |
2555 |
|
|
D Width of platform |
mm |
1830 |
|
|
E Track length |
mm |
2490 |
|
|
F Overall width of chassis |
mm |
1960 |
|
|
G Track shoe width |
mm |
400 |
|
|
H Wheel base of crawler |
mm |
1990 |
|
|
I Track gauge |
mm |
1560 |
|
|
J Counterweight clearance |
mm |
637 |
|
|
K Minimum ground clearance |
mm |
315 |
|
|
L Minimum tail swing radius |
mm |
1040 |
|
|
M Track height |
mm |
550 |
|
|
Working range |
A Maximum digging height |
mm |
5650 |
|
B Maximum dumping height |
mm |
4010 |
|
|
C Maximum digging depth |
mm |
3640 |
|
|
D Maximum depth cut for 2240mm(8 ft) level bottom |
mm |
3200 |
|
|
E Maximum vertical wall digging depth |
mm |
2690 |
|
|
F Maximum digging radius |
mm |
6110 |
|
|
G Minimum swing radius |
mm |
2430 |
|
|
Standard |
Length of boom |
mm |
2850 |
|
Length of arm |
mm |
1570 |
|
