China XCMG Official Manufacturer 50 Ton Crawler Excavator XE470D Hydraulic Mining Excavator Machine
Summary
- Rated Speed:2000rpm
- Max Digging Radius:10855mm
- Maximum Digging Depth:7000mm
- Maximum Digging Height:9855mm
- Bucket capacity:2.2~2.5m3
- Operating Weight:46900kg
- Model Number:XE470D
- Brand Name:XCMG
- Place of Origin:Jiangsu, China
Specifications
- Weight:46900.000kg
- Condition:New
- Moving Type:Crawler
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
China XCMG Official Manufacturer 50 Ton Crawler Excavator XE470D Hydraulic Mining Excavator Machine.
XE470D hydraulic excavator is one of the leading models of large excavators launched by XCMG excavator department. The product integrates the valuable experience gained by XCMG from years of research and development of excavator products, and adopts advanced design and manufacturing methods. Meanwhile, the product adheres to the design concept of "high efficiency, high safety, low carbon and environmental protection", and has perfect mine operation ability.
1. Ecological and economical
* Professional customized engine greatly improves fuel economy.
* Hydraulic oil flow regeneration system ensures optimum machine performance.
* Independent cooling system automatically adjusts fan speed.
2. Multiple applications
* Different boom, arm and bucket combinations can adapt to as many working conditions as possible.
* Multi-functional intelligent work tool control system can meet different operating requirements such as digging, breaking and dismanting.
* Instantaneous pressurization function copes with complex working conditions.
3.Comfortable operating experience
* Air Conditioner and Heator ensure the appropriate temperature.
* Silicone rubber shock absorber is adopted in the cab.
* Air-suspending seat equipped with electric heating function.
* Integrated control panel and large display screen provide multiple information.
* ROPS and FOPS Cab can improve cab safety.
|
Sales model |
Unit |
XE470D |
|
|
Operating weight |
Kg |
46900 |
|
|
Bucket capacity |
m³ |
2.2-2.5 |
|
|
Engine |
Model |
/ |
QSM11-335 |
|
No. of cylinders |
/ |
6 |
|
|
Output power |
kw/rpm |
250/2000 |
|
|
Maximum torque/speed |
N.m/rpm |
1790/1400 |
|
|
Displacement |
L |
11 |
|
|
Main performance |
Travel speed |
km/h |
5.4/3.2 |
|
Swing speed |
r/min |
9 |
|
|
Gradeability |
° |
35 |
|
|
Ground pressure |
kPa |
83 |
|
|
Bucket digging force |
kN |
287 |
|
|
Arm digging force |
kN |
221 |
|
|
Maximum traction |
kN |
338 |
|
|
Hydraulic system |
Rated flow of main pump |
L/min |
2×360 |
|
Main safety valve pressure |
MPa |
31.4/34.3 |
|
|
Travel system pressure |
MPa |
34.3 |
|
|
Rotary system pressure |
MPa |
28.4 |
|
|
Pilot system pressure |
MPa |
3.9 |
|
|
Oil Capacity |
Fuel tank capacity |
L |
725 |
|
Hydraulic tank capacity |
L |
430 |
|
|
Engine oil capacity |
L |
38 |
|
|
Appearance size |
A Overall length |
mm |
11670 |
|
B Overall width |
mm |
3582 |
|
|
C Overall height |
mm |
3890 |
|
|
D Width of platform |
mm |
2995 |
|
|
E Track length |
mm |
5353 |
|
|
F Overall width of chassis |
mm |
3582 |
|
|
G Track width |
mm |
600 |
|
|
H Length to center of rollers |
mm |
4292 |
|
|
I Track gauge |
mm |
2750 |
|
|
J Counterweight clearance |
mm |
1324 |
|
|
K Min. ground clearance |
mm |
519 |
|
|
L Min. tail swing radius |
mm |
3665 |
|
|
M Track height |
mm |
1198 |
|
|
Working scope |
A Max. digging height |
mm |
9855 |
|
B Max. dumping height |
mm |
6890 |
|
|
C Max. digging depth |
mm |
7000 |
|
|
D Maximum depth cut for 2240mm(8 ft) level bottom |
mm |
6900 |
|
|
E Max. vertical wall digging depth |
mm |
4500 |
|
|
F Max. digging radius |
mm |
10855 |
|
|
G Min. swing radius |
mm |
4580 |
|
|
Standard configuration |
Length of boom |
mm |
6670 |
|
Length of arm |
mm |
2900 |
|
|
Bucket capacity |
m³ |
2.5 |
|
|
Optional configuration |
Length of boom |
m³ |
7060 |
|
Length of arm |
m³ |
3380 |
|
|
Bucket capacity |
m³ |
2.2 Rock bucket 2.5 Strengthened bucket |
|
