XCMG new 37 ton big excavators XE370D Chinese large dragline crawler excavator machine price

XCMG new 37 ton big excavators XE370D Chinese large dragline crawler excavator machine.

XCMG XE370D hydraulic excavator as a model featuring strong power, excellent energy saving, outstanding environmental protection and strong durability, etc., and especially suitable for earthwork engineering, tunnels and other harsh construction environment.

performance and characteristics:

1. The overall layout and the axle load distribution are more reasonable to achieve better traveling stability and the maximum traveling speed is up to 40km/h to realize faster site transfer speed.

2. The domestic leading hydraulic system distribution technology features high energy-saving and efficiency.

3. The highest breakout force on the loading end is leading the industry by 15%~20% compared with like models.

4. The advanced structure and hinge points on the digging end and the industry’s largest rotating angle of the bucket ensure strong soil holding capacity.

XCMG new 37 ton big excavators XE370D Chinese large dragline crawler excavator machine price

Description			Unit	Parameter value
Operating weight			kg	36800
Bucket capacity			m³	1.4～1.8
Engine	Model		Engine	ISUZU GH-6HK1XKSC-03
	Style	Direct injection	---	√
		Four strokes	---	√
		Water cooling	---	√
		Turbo-charging	---	√
		Air to air intercooler	---	√
	No. of cylinders		---	6
	Output power		kW/ r/min	212/2000
	torque/speed		N.m	1080/1500
	Displacement		L	7.79
Main performance	Travel speed（H/L)		km/h	5.4/3.2
	Gradeability		%	70
	Rotary speed		r/min	9.7
	Ground pressure		kPa	66.7
	Bucket digging force		kN	263
	Arm digging force		kN	188
Hydraulic system	Main pump		--	K5V160DTH
	Rated flow of main pump		L/min	2×304
	Main safety valve pressure		MPa	34.3/37
	Pressure of pilot system		MPa	3.9
Oil Capacity	Fuel tank capacity		L	660
	Hydraulic tank capacity		L	350
	Engine oil capacity		L	30
Appearance size	Overall length		mm	11388
	Overall width		mm	3190
	Overall height		mm	3530
	Width of platform		mm	3050
	Length of crawler		mm	5035
	Overall width of chassis		mm	3190/600 Crawer、3290/700 Crawer、3390/800 Crawer
	Width of crawler		mm	600
	Wheel base of crawler		mm	4040
Working scope	Max. digging height		mm	10445
	Max. dumping height		mm	7287
	Max. digging depth		mm	7423
	Max. vertical wall digging depth		mm	6776
	Max. digging reach		mm	11114
	Min. swing radius		mm	4369
