XCMG 15 ton wheel excavator XE150WB wheeled excavator machine for sale
Summary
- Rated Speed:11/33KM/h
- Max Digging Radius:7780mm
- Machine Weight:15T
- Maximum Digging Depth:4630mm
- Maximum Digging Height:8190mm
- Bucket Capacity:0.58cbm
- Operating Weight:14t
- Model Number:XE150WB
- Brand Name:XCMG
- Place of Origin:Jiangsu, China
Specifications
- Weight:15000.000kg
- Condition:New
- Moving Type:Other
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG XE150WB 15 ton wheel excavator.
Main parameters:
Bucket capacity:0.58CBM
Max digging height:8190mm
Main configuration:
Cummins QSB4.5 engine 104kw
Hydraulic system
XE150WB plays an important role in the aspects of airport, port, oil field, urban construction, irrigation and water conservancy and rapid repair, and brings rich value returns for customers.
XE150WB wheeled hydraulic excavator is powerful, flexible and exquisite enough to cope with a variety of working conditions. The appearance size of the machine complies with road regulations and transportation requirements.
As a model featuring sufficient flexibility, high fuel efficiency and operation reliability in accordance with the North America and Euro-III emission standards,
This machine has used a new generation of independent researched and developed controllers as well as a low-noise pump and especially considered the matching between the engine and the low-speed load to make full use of the engine power, improve the working efficiency and effectively reduce the fuel consumption. The reliability during heavy-load operations can be satisfied by virtue of its lightweight chassis with high rigidity and strengthened key parts.
Model |
Unit |
XE150WB |
Engine model |
/ |
QSB4.5 |
Output power of engine |
Kw/r/min |
104/2000 |
Operating Weight |
KG |
14000 |
Max. torque/engine |
N.m |
586 |
Displacement |
L |
4.5 |
Fuel tank capacity |
L |
250 |
Rated flow of main pump |
L/min |
2x160 |
Pressure of main safety valve |
Mpa |
31.4/34.3 |
Hydraulic tank capacity |
L |
135 |
Slewing speed |
r/min |
12 |
Digging capacity of bucket |
KN |
95 |
Digging capacity of bucket rod |
KN |
72 |
Min. Turning radius |
mm |
6500 |
Rated speed |
KM/h |
11/33 |
Gradient capability |
% |
70 |
A Total length |
mm |
7778 |
B Total width |
mm |
2495 |
C Total height |
mm |
3305 |
Counterweight ground clearance |
mm |
1230 |
Min. ground clearance |
mm |
355 |
Min. tail swing radius |
mm |
2300 |
Wheelbase |
mm |
2800 |
Track gauge |
mm |
1920 |
Total width of chassis |
mm |
2495 |
Distance between front axle and turning center |
mm |
1700 |
Hood height |
mm |
2430 |
The maximum digging depth of dozer |
mm |
105 |
Max. digging radius |
mm |
7780 |
Min. swing radius |
mm |
7570 |
Max. digging height |
mm |
8190 |
Max. dumping height |
mm |
5855 |
Max. digging depth |
mm |
4630 |
Maximum depth cut for 2240mm(8 ft) level bottom |
mm |
4325 |
Max. vertical wall digging depth |
mm |
4150 |
