XCMG official 10 ton asphalt compactor XD103 China double drum vibratory rollers machine for sale, MACHMALL

Engineering & Construction Machinery > Road Construction & Maintenance Machinery > Road Roller

XCMG official 10 ton asphalt compactor XD103 China double drum vibratory rollers machine for sale

FOB Price: $55000.00-$60000.00

View All >

Model： XD103

Engine： DEUTZ

After-sales Service： Engineers available to service machinery overseas

Min Order Quantity： 1 Unit

Delivery Time：

In Stock (Within 7 days)

Production (Within15 to 20 days)

Customization (negociated delivery time)

After-sales Service：

1. It is recommended that you keep in touch with the seller after purchasing offline...

About after-sales service:

1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:

1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.

Inquiry Chat Now

Favorite Products

Product:

XCMG official 10 ton asphalt compactor XD103 China double drum vibratory rollers machine for sale

Quantity:

- + /EA

Content:

Or choose from these questions:

What is the best price you can offer?

Do you support customization?

What is the MOQ for this product?

*Email:

Full Name:

Mobile phone:

XD103

Specs & Compare

Details

Specs & Compare

Select 3 models for comparison

Weight

Dimension(L*W*H)

Power(W)

Model Number

Brand Name

Place of Origin

Grade Ability

Travel Speed

Static Linear Pressure

Type

Certification

Engineering & Construction Machinery

XD103

10000kg

4900*1750*3087mm

74.9kW

XD103

XCMG

China

35%

0~12km/h

Vibratory Roller

CE/ISO9001

+ Add a Product

Summary

Weight:10000kg
Dimension(L*W*H):4900*1750*3087mm
Power(W):74.9kW
Model Number:XD103
Brand Name:XCMG
Place of Origin:China
Grade Ability:35%
Travel Speed:0~12km/h
Type:Vibratory Roller
Certification:CE/ISO9001

Specifications

Weight:10000.000kg
Condition:New
Moving Type:Other

Packaging & Shipping

Delivery Lead Time:7 days for ready goods
Minimum Order:1 Piece
Supply Ability:10,000 Set/ Sets per Month
Total Quantity In Stock:Over 5000
Delivery Port:Any Port In China

XCMG official 10 ton asphalt compactor XD103 China double drum vibratory rollers machine for sale

XCMG official asphalt compactor XD103 Chinese double drum vibratory rollers machine.

XCMG XD103 asphalt compactor which is independent researched and developed by XCMG road machinery business division based on years of experience in compaction machinery research and development. It is designed for the compaction of asphalt pavement, asphalt layer of different materials and different thickness, especially suitable for roads, parking lots, airports and other large engineering projects, can also be used for compaction of roadbed and sub-base material, wide application scope.

Performance Characteristics:

*The console can rotate about 35 degrees, improving the driving comfort.

*The steering wheel can adjust angle according to the need of the driver.

*Control handle, display, etc. are arranged on the right side to broaden the front view.

*Speed frequency management system guides the user to compaction operation.

*Guiding the user to improve operation efficiency.

*The vibration drum realizes the center of four-in-one combination.

*Preventing the over-compaction and less-compaction.

XCMG official 10 ton asphalt compactor XD103 China double drum vibratory rollers machine for sale

Parameter		Unit	XD103
Weight distribution	Working weight	kg	10000
	Front wheel distribution weight (kg)		5000
	Rear wheel distribution weight (kg)		5000
Compaction performance	Static linear load	N/cm	280/280
	Nominal amplitude	mm	0.35/0.6
	Vibration frequency	Hz	58/48
	Exciting force (high frequency/low frequency)	kN	90/110
	Vibration wheel size	mm	1150*1750
Maneuverability	Speed range	km/h	0~6/0~12
	Theoretical gradeability	%	35
	Minimum turning radius (in/out)	mm	4070/5820
	Swing angle	°	±10
	Steering angle	°	±38
Engine	Rated power	kW	74.9
Engine	Rated speed	r/min	2300
