XCMG 100 Ton Mobile Truck Crane XCT100 All Terrain Truck Crane wheel crane machine for sale
Summary
- Model Number:XCT100
- Brand Name:XCMG
- Place of Origin:Jiangsu, China
- Span:5-25m
- Max. Lifting Height:88m
- Max. Lifting Load:100t
- Rated Lifting Moment:4704kN.m
- Rated Loading Capacity:100t
- Application:construction
- Certification:ISO9001/CE
Specifications
- Weight:55000.000kg
- Condition:New
- Moving Type:Wheel
- Color:Color
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG 100 Ton Mobile Truck Crane XCT100 All Terrain Truck Crane wheel crane machine.
Compactboom tail structure improves boom telescoping ratio, which effectively contributesto longer boom length. The boom with six sections can be extended up to 64m, 1mhigher than the longest boom in the class in the industry, with performanceimproved by 15~20%.
The latest control technology platform is adopted to update the system withthe realization of intelligent crane operations and travel control.
Road traveling and tight turning radius modes are available throughrear-axle hydraulic control servo steering technology to ensure stablehigh-speed driving and flexible low-speed driving.
|
Description |
Unit |
Parameter value |
|
Overall length |
mm |
15600 |
|
Overall width |
mm |
3000 |
|
Overall Height |
mm |
3870 |
|
Wheel Base |
mm |
1920+3500+1420+1505 |
|
Track(front/rear) |
mm |
2449/2315 |
|
Front/Rear overhang |
mm |
2650/2765 |
|
Front/Rear extension |
mm |
1840/0 |
|
Total vehicle mass in travel configuration |
kg |
55000 |
|
Axle load |
kg |
10000 |
|
kg |
13000 |
|
|
kg |
9000 |
|
|
Engine Model |
WP6G240E330 |
|
|
Engine rated power |
kw/(r/min) |
176/2300 |
|
Engine rated torque |
N.m/(r/min) |
860/1200-1700 |
|
Max. travel speed |
km/h |
90 |
|
Min. turning diameter |
m |
23 |
|
Min. ground clearance |
mm |
326 |
