XCMG Official XC740K wheel skid steer loader 1ton mini skid steer loader machine for sale
Summary
- Rated Load:750kg
- Dimension(Long*Breadth*High):3270*1807*1970mm
- Type:Skid Steer Loader
- Place of Origin:Jiangsu, China
- Model Number:XC740K
- Brand Name:XCMG
- Certification:CE/ISO9001
Specifications
- Weight:3140.000kg
- Condition:New
- Moving Type:Other
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG
Official XC740K wheel skid steer loader 1ton mini skid steer loader machine.
XC740K
with strong power and rich attachments, the XCMG skid-steer loader can better
adapt to the operations in narrow space and is an ideal tool for road
construction, municipal maintenance, port handling, garden maintenance, and
pasture production, featuring low operation cost and remarkable economic
benefits.
Advantages
and Highlights:
1. Strong
and Efficient Power Transmission System
* The
renowned brand engine equipped features strong power, ultra-low emission, and
higher fuel efficiency.
* The static hydraulic drive technology adopted features stable
drive and high efficiency and reliability.
* The fully-sealed sprocket case and high strength chains feature
automatic lubrication and maintenance-free.
2. Solid
and Reliable Design
The
integral frame adopted features compact structure and high firmness and
reliability. All critical structural parts are optimized through finite element
analysis to realizereasonable stress distribution.
3.
Flexible Operations
The bucket
can automatically maintain level status during lifting to prevent scattering of
material and improve working efficiency.
4.
Incomparable Multi-Functionalities
The
international interchangeable quick-change coupling enables the change of tens
of attachments, including sweeper, planer, breaking hammer, and ditcher,
rapidly and conveniently.
|
Description |
Unit |
Parameter value |
|
|
Rated load |
kg |
750 |
|
|
Tipping load |
kg |
1500 |
|
|
Operating weight |
kg |
3140 |
|
|
Maximum breakout force |
kN |
18 |
|
|
Engine |
Manufacturer |
Xinchai |
|
|
Model |
4D27G31 |
||
|
Rated power |
Hp/kw |
49.3/36.8 |
|
|
Rated speed |
rpm |
2500 |
|
|
Cooling mode |
Water-cooling |
||
|
Performance parameter |
Operation mode |
Mechanical & multi-function
electronic control |
|
|
Tire standard |
10-16.5 |
||
|
Maximum speed |
Km/h |
14 |
|
|
Hydraulic system |
Hydraulic flow rate |
L/min |
62.5 |
|
Optional large flow |
-- |
||
|
Hydraulic pressure |
bar |
200 |
|
|
Maximum operating height |
mm |
3878 |
|
|
Bucket hinge pin height |
mm |
3057 |
|
|
Cabin top height |
mm |
1960 |
|
|
Maximum horizontal height of bucket
bottom |
mm |
2851 |
|
|
Length without bucket |
mm |
2533 |
|
|
Length with bucket |
mm |
3310 |
|
|
Toppling angle |
° |
40 |
|
|
Maximum unloading height |
mm |
2375 |
|
|
Ground-bucket angle |
° |
30 |
|
|
Rotating angle of bucket at highest point |
° |
83 |
|
|
Unloading distance |
mm |
575 |
|
|
Wheel base |
mm |
1027 |
|
|
Departure angle |
° |
25 |
|
|
Ground clearance |
mm |
183 |
|
|
Front radius of turning circle (without
bucket ) |
mm |
1183 |
|
|
Front radius of turning circle (with
bucket) |
mm |
2066 |
|
|
Rear radius of turning circle |
mm |
1564 |
|
|
Length of tail |
mm |
1005 |
|
|
Wheel track |
mm |
1380 |
|
|
Tire edge width |
mm |
1640 |
|
|
Bucket edge width |
mm |
1800 |
|
|
Bucket capacity (stacking height) |
m³ |
0.45 |
|
|
Bucket capacity (tiling) |
m³ |
0.35 |
|
|
Diesel tank capacity |
L |
80 |
|
|
Capacity of hydraulic oil tank |
L |
60 |
|
