XCMG Second Hand GR2605 Hydraulic Road compact motor graders Grader Factory Price

FOB Price: $240998.000

View All >

Model： GR2605

After-sales Service： Engineers available to service machinery overseas

Min Order Quantity： 1 Unit

Delivery Time：

In Stock (Within 7 days)

Production (Within15 to 20 days)

Customization (negociated delivery time)

After-sales Service：

1. It is recommended that you keep in touch with the seller after purchasing offline...

About after-sales service:

1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:

1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.

Inquiry Chat Now

Favorite Products

Product:

XCMG Second Hand GR2605 Hydraulic Road compact motor graders Grader Factory Price

Quantity:

- + /Set

Content:

Or choose from these questions:

What is the best price you can offer?

Do you support customization?

What is the MOQ for this product?

*Email:

Full Name:

Mobile phone:

GR2605

Specs & Compare

Details

Specs & Compare

Select 3 models for comparison

Certification

Dimension(L*W*H)

Weight

Model Number

Brand Name

Place of Origin

Reverse Speed(km/h)

Forward Speed(km/h)

Used Equipment

GR2605

944X262X347 cm

19000

GR2605

XCMG

Jiangsu, China

4.9、11、24.7 km/h

4.9、8、11、17.9、24.7、40.2 km/h

+ Add a Product

Summary

Certification:-
Dimension(L*W*H):944X262X347 cm
Weight:19000
Model Number:GR2605
Brand Name:XCMG
Place of Origin:Jiangsu, China
Reverse Speed(km/h):4.9、11、24.7 km/h
Forward Speed(km/h):4.9、8、11、17.9、24.7、40.2 km/h

Specifications

Weight:19000.000kg
Condition:Used
Moving Type:Wheel
Rated power/speed:194kW/2100rpm

Packaging & Shipping

Delivery Lead Time:7 days for ready goods
Minimum Order:1 Piece
Delivery Port:Any Port In China

XCMG Second Hand GR2605 Hydraulic Road compact motor graders Grader Factory Price

Utilizing load sensitive hydraulic system, small control force, good control feeling, more sensitive.

Engine variable power control technology, more energy efficient.

Intelligent fan control technology enables fan speed changing with the real-time detected system temperature, low energy consumption and low noise.

Two Electric joysticks control. The Joysticks can control all cylinders、steering、gear selection、differential Lock/Unlock, etc.

The rear axle with oil bathed, multi-disc service brakes, has long lifetime and higher reliability.

The ROPS &FOPS cab is adopted for higher safety. Optimized internal control and internal overall layout to meet ergonomic requirements with higher comfort.

Optimal arrangement of the air conditioning flue, integration with cab interior design, better air conditioning effect.

Advance ant vibration and noise reduction technology, low noise of the whole machine.

The working device is more reliable with the integral angle position device, high strength rotary support and overload protection worm gearbox.

Optimize the layout of the whole machine, realize the fuel filling on the ground, optimize the layout of maintenance points, make the maintenance more convenient.

Double emergency stop control. the whole machine is equipped with two emergency stop buttons, one is in the cab and the other one is located outside the machine, to provide the better safety for users.

Equipped with reversing image system to enlarge the rear view and improve the safety.

With fault diagnosis function, it can conveniently inquire the fault information.

Advantages and highlights:

1.Offer Test Report of Professional Institute.

2.Details Of Maintenance And Repair Items Included.

3.Price Concessions.

4.Official Factory Sourcing.

5.Reconditioning Directly From XCMG.

6.Vehicle Condition of Perfection.

7.XCMG Official Endorsement.

8.SGS Provides The Third-Party Inspection Certificate.

Item			GR2605
Basic parameter	Engine type		L9
	Rated power/Speed		194kW/2100rpm
	Machine dimension(standard)		9448×2625×3472mm
	Machine weight(standard)		19000 kg
	Tire specification		17.5R25
	Ground clearance (Front axle)		592mm
	Wheel base		2156mm
	Axle distance between front and rear		6545mm
	Wheel base between middle and rear		1696mm
Performance parameter	Forward speed		4.9、8、11、17.9、24.7、40.2km/h
	Rearward speed		4.9、11、24.7km/h
	Traction force f=0.75		≥99kN
	Maximum gradeability		≥25%
	Inflation pressure of tire		425kPa
	Work system pressure		24.5MPa
	Transmission pressure		1.85-2.2Mpa
Working parameters	Maximum steering angle of front wheel		±49°
	Allowable angle of inclination of front wheel		±18°
	Maximum swinging angle of front axle		±16°
	Maximum swinging angle of balance box		Front 15°, rear 15°
	Maximum swinging angle of frame		±25°
	Minimum turning radius		7.6m
	Blade	Maximum lifting height	452mm
		Maximum scraping depth	755mm
		Maximum tilt angle	90°
		Cutting angle	前40°，后5°
		Angle of revolution	360°
		Length × Height	4270×610mm
Oil filling capacity	Coolant		50L
	Fuel tank		352L
	Engine		24L
	Transmission box		38L
	Balance box		105L per
	Drive axle		35L
	Hydraulic oil		193L

XCMG STORY

XCMG RECONDITIONED MACHINE

XCMG reconditioned machine is the second-hand machine program launched by XCMG for the post market. XCMG takes advantage of its dealers network to collect the second-hand XCMG machine that falls into strict standards: good condition, full function and low service hours. The returned machine is then disassembled, repaired, painted, rebuilt and tested officially by XCMG, and the product life is therefore extended. The price of XCMG reconditioned machine is far lower than that of the new one, but its performance and safety are not compromised thanks to XCMG's state-of-the-art processes and technologies. In order to dispel customers' concerns, XCMG establishes a strict evaluation system for reconditioned machines and invites SGS to issue third-party certification.

OUR TEAM

150+ SPECIALISTS

150+ specialists participate in the reconditioning process.

Inspection Team

Certified professional accessors who have worked for more than 10 years conduct comprehensive analysis on the machine.

Reconditioning and Repairing Team

Refurbish core parts to restore capacity. Replace all worn parts with genuine XCMG new ones.

Issuing Report Team

Certified examiner inspects, tests and certifies the reconditioned machine. SGS provides the third-party inspection certificate.

OUR FACTORY

REMANUFACTURING FACTORY

RECONDITION PROCESSES

RECONDITION PROCESSES OF THE USED

We maintain a meticulous and rigorous attitude toward quality, focusing on extraordinary creativity, elaborate designs and exquisite craftsmanship.

COLLECTION

Examine the working conditions, conduct static and dynamic assessment on the used machine. Only machines with light deprecation, low working hours and full functions can be collected.

INSPECTION

Certified professional accessors who have worked for more than 10 years conduct comprehensive analysis on the machine. More than 300 details are checked and compared to XCMG standard. Recondition plan is then decided.

RECONDITIONING AND REPAIRING

Refurbish core parts to restore capacity. Replace all worn parts with genuine XCMG new ones.

TESTING

Follow the test procedure, ensure the performance and durability of the machine. Unqualified products are returned to step 3.

READY FOR DELIVERY

Ready for Delivery!!!

ISSUING REPORT

Certified examiner inspects, tests and certifies the reconditioned machine. SGS provides the third-party inspection certificate.

PAINTING

The whole machine is repainted to restore its appearance. Bright as new.

FAQ

FREQUENTLY ASKED QUESTIONS

1.What’s the warranty policy for XCMG reconditioned machines?

The warranty policy does not cover the covering parts and wearing parts. For engine, gearbox, hydraulic pump, distriutor valve and electric system, the warranty period will be 3 months or 500 working hours whichever comes first. If there is any problem within warranty period, XCMG will provide solutions accordingly.

2.How about the quality of your machine?

The procedure of recondition is taking the same criterion of brand new XCMG machines, therefore, quality of machines will be guaranteed. They are ready to work for you and XCMG will provide test report from professtional institute.

3.Are you the original manufacturer?

Yes! XCMG is leading construction machinery industry in China and XCMG can provide a complete range of constrcution machineries.

4.Can you satisfy my special requirement?

As the manufacturer,XCMG will review the special requirement and recondition it as per request (if possible).

5.What is accpetable payment terms?

Usually XCMG will accept T/T before shipment or 100% Letter of Credit at sight.
If any other questions, please feel free to contact with us.
