XCMG SQ12SK3Q rc hydraulic truck mounted crane for sale in japan
Summary
- Certification:CE/ISO9001
- Model Number:SQ12SK3Q
- Brand Name:XCMG
- Place of Origin:Jiangsu,China
- Span:2270~5270mm
- Max. Lifting Height:14.7m
- Max. Lifting Load:12t
- Rated Lifting Moment:30t.m
- Application:Construction
Specifications
- Weight:4316.000kg
- Condition:New
- Moving Type:Wheel
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG SQ12SK3Q rc hydraulic truck mounted crane in japan.
* Single cylinder synchronization guy cable technology makes work efficiency higher than before.
* Advanced development means make sure that the design is very reliable.
* The more symmetrical center design of pentagon or hexagon boom make it has bigger anti-bending capacity.
* Compact hinge point design takes up smaller space.
* The work is more safety after fitted with alarm device.
* The integer lifting winch improved the work efficiency greatly and prolonged work life of hydraulic system.
* Float three –point bridge structure design can lower the accessional stress on the chassis when traveling.
* It has been fitted own powerful slewing of working in diversifying conditions.
* Anti-slewing impulse equipment makes vehicle running safety.
Description |
Unit |
Parameter value |
|
Max Lifting Moment |
t*m |
30 |
|
Max Lifting Capacity |
kg |
12000 |
|
Boom Length |
m |
5.26~12.91 |
5.64~14.45 |
Max Lifting Height |
m |
14.7 |
16.2 |
Derricking range |
° |
0~75° |
|
Outrigger span |
mm |
2270~5270 |
2310~5700 |
Size(length×width×height) |
mm |
5598×2490×3306 |
5677×2576×3290 |
Crane Weight |
kg |
4316 |
4460 |
