XCMG 90 ton Rough Terrain Crane Hydraulic crane RT90U 4 wheel crane terrain rough for sale
![](/app/topc/statics/images/close.png)
![XCMG 90 ton Rough Terrain Crane Hydraulic crane RT90U 4 wheel crane terrain rough for sale](/images/store/357636/item/RT90 AAA (15).jpg)
![](/app/topc/statics/images/close.png)
Summary
- Model Number:RT90U
- Brand Name:XCMG
- Place of Origin:Jiangsu, China
- Span:7.6m
- Max. Lifting Height:50m
- Max. Lifting Load:90 ton
- Rated Lifting Moment:3140 kN.m
- Rated Loading Capacity:90 ton
- Application:construction
- Certification:TÜV/ISO9001
Specifications
- weight:58000.000kg
- Condition:New
- Moving Type:Other
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG 90ton Rough
Terrain Crane RT90U.
RT90U
is a high-end model developed by XCMG and an experienced R&D institute in
Europe, which has been approved by CE in Europe. The product is equipped with
two-axle loading chassis and has two types of driving model, four types of
turning models and back-and-forward driving function. The product has five
sections of quadrangular great circle main doom, H-type outrigger as well as
combined self-removal and installation counterweight. It has three types of
operation models such as operation with the support of outrigger, operation
with the support of tire and hanging when driving. It is widely used in oil
field, mine, road and bridge construction, warehousing base and other
construction sites.
Feature:
1.Strong
Power of Hoisting, Wide Range of Work
It
has 31m main booms, 13m auxiliary booms, with the longest main booms and the
highest comprehensive hoisting performance in the product of the same tonner.
2.Maneuvering
and Flexible, Quick and Efficient
The
max speed reaches 50km/h and the max gradeability is 55% and the min. turning
radius is 5m. All these three factors make it flexible.
Self-localization
and self-locked Jib stowed under booms make it needs no auxiliary operator and
no equipment, and can quickly retract, and efficiently work.
3.Safe
and Reliable, No Worry to Handle
The
product is equipped with lifting protection control system in case of overload,
over-retracting and over-stretching as well as exclusive technology in this
field like rear axle-wheel automatic return-control system and safety-driving
automatic protection system. All these elevate its safety performance largely;
The
product is equipped with top features in this field, professional matching
upgrading and systematic evaluation test. And it has passed test like driving
11,000km and 10,000 times hanging. Both ensure its reliability.
4.Economic
and Environmental Protection, with Cost Saving
The
product is equipped with optical matching power transmission system and torque
converter with lockout function, which decrease the oil consumption over 20% at
high speed.
The
one-way stabilized current control of parallel hydraulic pressure system
reduces the loss of flow; the gravity drop luffing system needs no extra power
and save the oil consumption.
5.Comfortable
to Handle, Convenient to Operate
The
product is equipped with full hydro-steering control system and
automatic-manual gear box, which make it easy to handle. And the compounded
suspension of leaf spring and hydraulic oil tank, and the self-recognition
phased control of rotary cushion technology make the operation stability and
comfortable;
The
product is equipped with humanized climb ladder, maintenance access and control
layout. And it is equipped with professional man-machine engineering simulation
analysis; exquisite man-machine interface and stand-alone fault diagnose
function. It is comfortable to handle and convenient to operate.
Dimension |
Unit |
XCM RT90U |
Overall length |
mm |
14067 |
Overall width |
mm |
3400 |
Overall height |
mm |
3990 |
Weight |
|
|
Total weight in travel |
kg |
58000 |
Power |
|
|
Engine model |
QSL |
|
Engine rated power |
kW/(r/min) |
209 |
Engine rated torque |
N.m/(r/min) |
949 |
Travel |
|
|
Max. travel speed |
km/h |
36 |
Min. turning diameter |
m |
15 |
Min. ground clearance |
mm |
440 |
Approach angle |
° |
22.5 |
Departure angle |
° |
20 |
Max. grade ability |
% |
60 |
Fuel consumption for 100km |
L |
- |
Main performance |
|
|
Max. rated total lifting capacity |
t |
80(90Ust) |
Min. rated working radius |
m |
3 |
Turning radius at turntable tail |
m |
4.625 |
Max. lifting torque |
kN.m |
3140 |
Full-extend boom |
m |
12.4 |
Full-extend boom+jib |
m |
46.2 |
Boom length |
m |
60.2 |
