XCMG Official 60 Ton New Rough Terrain Crane RT60A China Tractor Hydraulic Crane for Sale
.jpg)
Summary
- Model Number:RT60A
- Brand Name:XCMG
- Place of Origin:Jiangsu,China
- Max. Lifting Height:49.1m
- Rated Lifting Moment:2058kN.m
- Rated Loading Capacity:60t
- Application:Construction
- Certification:CE/ISO9001
Specifications
- Weight:60000.000kg
- Condition:New
- Moving Type:Wheel
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG Official 60 Ton New Rough Terrain Crane RT60A China Tractor Hydraulic Crane.
RT60A is a high-end model developed by XCMG and an experienced R&D institute in Europe, which has been approved by CE in Europe.
The product is equipped with two-axle loading chassis and has two types of driving model, four types of turning models and back-and-forward driving function.
The product has four sections of quadrangular great circle main doom, H-type outrigger as well as combined self-removal and installation counterweight.
It has three types of operation models such as operation with the support of outrigger, operation with the support of tire and hanging when driving.
It is widely used in oil field, mine, road and bridge construction, warehousing base and other construction sites.
|
Project |
Unit |
Parameter |
|
Length of Entire Vehicle |
(mm) |
13300 |
|
Width of Entire Vehicle |
(mm) |
3180 |
|
Height of Entire Vehicle |
(mm) |
3889 |
|
Wheel Base |
(mm) |
4000 |
|
Wheel Track |
(mm) |
2400 |
|
Gross Vehicle Weight When Driving |
(kg) |
40810 |
|
Axle Load |
(kg) |
(Front Axle)21070(Rear Axle)19740 |
|
Engine Type |
- |
QSB6.7 |
|
Engine Rated Power(kw/ |
(kw/(r/min)) |
194 |
|
Engine Max Torque(N.m/ |
(N.m/(r/min)) |
990 |
|
Max Travel Speed |
(km/h) |
35 |
|
Min Travel Speed |
(km/h) |
2 |
|
Min Turning Radius |
(m) |
12.2 |
|
Head Min. Turning Diameter |
(m) |
- |
|
Max Gradeability |
(%) |
65 |
|
Min. Ground Clearance of Machine |
(mm) |
495 |
|
Approach Angle |
(°) |
20 |
|
Departure Angle |
(°) |
17 |
|
Braking Distance |
(m) |
9 |
|
Max. Rated Lifting Capacity |
(t) |
60 |
|
Min. Rated Range |
(m) |
3 |
|
Max. Load Moment of Basic Jib |
(kN·m) |
2058 |
|
Radius of Gyration of Turntable Tail |
(mm) |
4220 |
|
Longitudinal |
(m) |
7.3 |
|
Horizontal |
(m) |
7.2/5.6 |
|
Basic Boom |
(m) |
11.3 |
|
Longest Main Boom |
(m) |
35.8 |
|
Longest Main Boom + Auxiliary Boom |
(m) |
49.1 |
|
Basic Boom |
(m) |
11.32 |
|
Longest Main Boom |
(m) |
35.5 |
|
Longest Main Boom + Auxiliary Boom |
- |
51.5 |
|
Max. Slewing Speed |
(r/min) |
2.5 |
|
Main Hoisting Mechanism |
(m/min) |
110(Unload) |
|
Auxiliary Hoisting Mechanism |
(m/min) |
110(Unload) |
