XCMG Official 35 ton hydraulic Rough Terrain Crane RT30 cranes terrain rough for sale
Summary
- Model Number:RT35
- Brand Name:XCMG
- Place of Origin:Jiangsu, China
- Span:2250~10000mm
- Max. Lifting Height:44m
- Max. Lifting Load:35 ton
- Rated Lifting Moment:1445.5kn.m
- Rated Loading Capacity:35 ton
- Application:construction
- Certification:CE/ISO9001
Specifications
- Weight:30360.000kg
- Condition:New
- Moving Type:Other
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG Official 35 ton hydraulic Rough Terrain Crane RT30
1, Specialized energy-saving hydraulic system.
2, Due to powerful power configuration, specific off-road tires and all-wheel drive, the crane can easily handle various tough terrains.
3, The crane is designed by conforming with the safety standards of Europe, North America and China, for optimal active protection.
4, Developed jointly by Chinese and German engineers, with advanced design concept.
5, Accumulation of experience in boom crane design for 70 years.
6, Top class modern plate machining center, and first class NC machining center.
Dimension |
Unit |
XCM RT35 |
Overall length |
mm |
11952 |
Overall width |
mm |
2980 |
Overall height |
mm |
3450 |
Weight |
|
|
Total weight in travel |
kg |
30360 |
Power |
|
|
Engine model |
|
QSB6.7-C190 |
Engine rated power |
kW/(r/min) |
142 |
Engine rated torque |
N.m/(r/min) |
616 |
Travel |
|
|
Max. travel speed |
km/h |
38 |
Min. turning diameter |
m |
11.4 |
Min. ground clearance |
mm |
400 |
Approach angle |
° |
23 |
Departure angle |
° |
20 |
Max. grade ability |
% |
55 |
Fuel consumption for 100km |
L |
- |
Main performance |
|
|
Max. rated total lifting capacity |
t |
35 |
Min. rated working radius |
m |
3 |
Turning radius at turntable tail |
m |
3.885 |
Max. lifting torque |
kN.m |
1445.5 |
Full-extend boom |
m |
9.7 |
Full-extend boom+jib |
m |
31.7 |
Boom length |
m |
45.1 |
