XCMG Official 30 Ton Crane Truck QY30K5-I China Truck with Crane for Sale
Summary
- Model Number:QY30K5-I
- Brand Name:XCMG
- Place of Origin:China
- Max. Lifting Height:48m
- Rated Lifting Moment:1025KN.m
- Rated Loading Capacity:30t
- Application:Construction
- Certification:CE/ISO9001
Specifications
- Weight:30000.000kg
- Condition:New
- Moving Type:Other
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG Official 30 Ton Crane Truck QY30K5-I China Truck with Crane for Sale.
1. Specialized boom of octagonal cross section has features of light deadweight, better strength and strong lifting capacity.
2. Advanced built-in boom head, strong structural members and lower sliders with larger area contribute to better stress-bearing capacity and more smooth telescoping movement, and efficiently prevent boom torsion after side loading.
3. Telescoping mechanism is designed reliably. In the telescoping mechanism, both rotation-resistant rope used for thick cable and guide pulley bearing are imported parts and have reliable performance.
4. Excellent welding technology for structural members. Welding robot with advance process used for key welding make reliable quality products.
5. Ferrule-type compression joints are used for pipeline, have features of reliable connection, better tightness and less leakage.
|
Description |
Unit |
Parameter value |
|
Overall length |
mm |
12570 |
|
Overall width |
mm |
2500 |
|
Overall Height |
mm |
3390 |
|
Wheel Base |
mm |
5025+1350 |
|
Track |
mm |
2074/1834/1834 |
|
Total vehicle mass in travel configuration |
kg |
32400 |
|
Axle load Front axle |
kg |
7600 |
|
Axle load Rear axle |
kg |
24800 |
|
Engine Model |
SC8DK280Q3 |
|
|
Engine rated power |
kw/(r/min) |
206/2200 |
|
Engine rated torque |
N.m/(r/min) |
1112/1400 |
|
Max. travel speed |
km/h |
80 |
|
Min. turning diameter |
m |
22 |
|
Min. ground clearance |
mm |
291 |
|
Max. grade ability |
% |
40 |
|
Approach angle |
° |
19 |
|
Departure angle |
° |
13 |
|
Braking distance (at 30 km/h, full load ) |
m |
≤10 |
|
Oil consumption per 100km |
L |
40 |
|
Exterior noise level during acceleration traveling |
dB (A) |
88 |
|
Noise level at seated position |
dB (A) |
90 |
