XCMG 70 ton 6*4 375HP cheap dump truck NXG5650DT off road mining mine discount dump truck on sale
Summary
- Horsepower:351 - 450hp
- Drive type:6x4
- Emission Standard:3900+1600mm
- Gross vehicle weight:70000kg
- Model Name:NXG5650DT
- Place of Origin:Xuzhou,Jiangsu,China
- Certification:CE/ISO9001
Specifications
- Weight:70000.000kg
- Dimensions (L x W x H) :8875*3335*3915mm
- Max. travel speed:50km/h
- Capacity (Load):41 - 50t
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
70 ton 6*4 375HP cheap dump truck NXG5650DT off road
mining mine discount dump truck.
XCMG NXG5650DT dump truck Dual-circuit brake system
equipped with high pressure geography accumulator volume increases, the brake
pressure increasing 25% to 1 Mpa, shorten braking distance.
Advantages and highlights:
* According to each of the engine torque characteristic
curve, perfectly match the different types of Fast manual gearbox, Allision
automatic gearbox, to protect the most energy rationalization output, the
vehicle has an excellent starting ability, climbing ability.
* Optimized arrangement of the traditional system
architecture, reducing the loss of energy transfer process to ensure the
kinetic energy efficient, rapid transmission.
* Using the unique steering and steering follower, the
steering mechanism. Steering light, the failure rate lower.
|
Dimensions |
Overall size (length×width×height) |
8875×3335×3915mm |
||
|
||||
|
Cargo body
size (length×width×height) |
5800×3150×1650mm |
|||
|
Cargo thickness |
Bottom 16mm ,sideboard 12mm |
|||
|
Wheelbase |
3900+1600 |
|||
|
Weight |
Kerb mass |
25000kg |
||
|
Rated loading
capacity |
45000kg |
|||
|
Gross vehicle weight |
70000kg |
|||
|
Performance |
Max. travel
speed |
50km/h |
||
|
Max. gradeability |
40% |
|||
|
Engine |
Rated output
power |
375HP（277kw） |
||
|
Displacement |
11596ml |
|||
|
Fuel tank |
Capacity |
400L |
