XCMG Official Tipper Truck Nxg5550Dt 50 Ton 6x4 Off-road Dump Truck Tipper
![](/app/topc/statics/images/close.png)
![XCMG Official Tipper Truck Nxg5550Dt 50 Ton 6x4 Off-road Dump Truck Tipper](/images/store/357636/item/NXG5550DT (1).jpg)
![](/app/topc/statics/images/close.png)
Summary
- Dimension(L*W*H):8860*3275*3740
- Weight:50 ton
- Brand Name:XCMG
- Certification:CE/ISO9001
- Dimension(L*W*H):8860*3275*3740mm
- Weight:50t
- Voltage:24V
- Usage:Mining
- Model Number:NXG5550DT
- Brand Name:XCMG
- Place of Origin:Jiangsu, China
- Power Type:Diesel
Specifications
- weight:50000.000kg
- Condition:New
- Moving Type:Other
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG Official Tipper Truck Nxg5550Dt 50 Ton 6x4 Off-road Dump Truck Tipper.
* According to each of the engine torque characteristic curve, perfectly match the different types of Fast manual gearbox, Allision automatic gearbox, to protect the most energy rationalization output, the vehicle has an excellent starting ability, climbing ability.
* Optimized arrangement of the traditional system architecture, reducing the loss of energy transfer process to ensure the kinetic energy efficient, rapid transmission.
* Using the unique steering and steering follower, the steering mechanism. Steering light, the failure rate lower.
* Dual-circuit brake system equipped with high pressure geography accumulator volume increases, the brake pressure increasing 25% to 1 Mpa, shorten braking distance.
Dimensions(mm) | Overall size (length×width×height) | 8860*3275*3740 |
Cargo body size (length×width×height) | 5800*2400*1650 | |
Cargo thickness | Bottom 16mm, sideboard 12mm | |
Wheelbase | 4000+1400 | |
Weight(kg) | Kerb mass | 17000 |
Rated loading capacity | 30000 | |
Gross vehicle weight | 47000 | |
Performance | Max. travel speed | 65km/h |
Min. turning Radius | 18.8m | |
Max. gradeability | 33% | |
Electric System | Operating voltage | 24V |
Alternator | 70A/28V | |
Batteries | 6-QAW-180DMF |
