XCMG Brand New Tractor Tuck Head 430hp Chinese Trucks 6*4 77 Ton NXG4250D3WC For Myanmar Sale
Specifications
- Weight:10400.000kg
- Condition:New
- Moving Type:Other
- Driving Type:right
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG Brand New Tractor Tuck Head 430hp
Chinese Trucks 6*4 77 Ton NXG4250D3WC For Myanmar.
XCMG joint global
advanced technology, widely used in the internationalization of professional
team, 3 years meticulously HANVAN han wind heavy card, accumulative total
examination of more than 200 kilometers, is more reliable and safer, more
comfortable, more economical, more environmental protection of a new generation
of high-end heavy card.
HANVAN han wind tractor
is mainly suitable for long-haul high-speed logistics, the average distance of
300 km/h to 5000 km/h, can be widely used to transport the following goods:
1.daily industrial
products: cold chain, valuables, tobacco, express delivery.
2.daily industrial
products: food, fruit, wood, stores, department stores, container, bulk.
3. iron powder, steel,
iron powder, iron ore, finished product profile.
4. bulk tank: cement,
lime, fly ash and other industrial powder.
5. dangerous goods:
oil, natural gas, chemical liquid.
6. ballast, sand, sand
and gravel.
|
Vehicle model |
XGA4180D3WA |
||
|
Mass parameter |
Curb weight |
7120kg |
|
|
GCW |
42000(With trailer）kg |
||
|
Traction mass |
34750kg |
||
|
Performances |
Max Speed |
90km/h |
|
|
Min. turning diameter |
12.5m |
||
|
Grade ability |
≥25% |
||
|
Hill-hold ability |
≥20% |
||
|
Fuel Tank |
400L |
||
|
Dimensions |
Overall dimensions |
Length |
6000mm |
|
Width |
2500mm |
||
|
Height |
3568/3930mm（With wind deflector） |
||
|
Wheelbase |
3600mm |
||
|
Wheel tread |
Front |
2059mm |
|
|
Rear |
1864mm |
||
|
Min. Clearance |
285mm |
||
|
Approach angle |
18° |
||
|
Departure angle |
47° |
||
|
Front overhang |
1500mm |
||
|
Rear overhang |
1000mm |
||
|
Cab |
Model |
G7LH |
|
|
Passengers |
2 |
||
|
Engine |
Model |
WP10. 375N |
|
|
Displacement |
9.726L |
||
|
Output power |
276kW |
||
|
Max torque speed |
1460N·m |
||
|
Clutch |
Model |
Φ430 Pull type diaphragm spring clutch |
|
|
Operation |
Hydraulic control with air booster |
||
|
Transmission |
Model |
12JSD200TA |
|
|
Manipulation |
Flexible shaft |
||
|
Forward ratio |
15.53/12.08/9.39/7.33/5.73/4.46/3.48/2.71/2.1/1.64/1.28/1 |
||
|
Reverse ratio |
14.86/3.33 |
||
|
Driven axle |
Model |
13T HANDE |
|
|
Ratio |
4.266 |
||
|
Brake type |
Drum type |
||
|
Differential lock |
Differential lock between axles and wheels |
||
|
Front axle |
Model |
7.5T |
|
|
Brake type |
Drum type |
||
|
Tire |
Rim |
9.0×22.5/8.5V-20 |
|
|
Tire |
315/80R22.5/12.00R20 |
||
|
Frame |
Type |
Straight beam of equal width |
|
|
Main beam |
300×80×8mm |
||
|
Auxiliary beam |
284×70×8mm |
||
|
Width of chassis
structure |
865mm |
||
|
Suspension |
Front |
Type |
Little lea spring |
|
Amount of spring plate |
3 |
||
|
Rear |
Type |
Multi-spring |
|
|
Amount of spring plate |
7 |
||
|
Steering |
Steering type |
Φ120 /Φ120 Circulating ball type hydraulic power |
|
|
Ratio |
23.27 |
||
|
Max pressure of pump |
17MPa |
||
|
Brake |
Rated working pressure |
1MPa |
|
|
Driving brake |
Dual circuit pneumatic braking |
||
|
Parking brake |
Spring energy storage air brake |
||
|
Assistant brake |
Engine exhaust brake |
||
|
Electric System |
Voltage |
24V |
|
|
Generator power |
2.2kw |
||
|
Battery voltage and
capacitance |
2×12V/165Ah |
||
