XCMG high quality wheel loader 8 ton LW800K large front loader
Summary
- Rated Load:8000kg
- Dimension(Long* Breadth * High):9300*3210*3770mm
- Type:wheel loader
- Place of Origin:Jiangsu, China
- Model Number:LW800K
- Brand Name:XCMG
- Certification:CE/ISO90001
Specifications
- Weight:28500.000kg
- Engine Brand:CUMMINS
- Rated Load:other
- Bucket Capacity:
- Bucket capacity:4.5m3
- Machine Weight:28500kg
- Max. dumping height:3400mm
- Power:250KW
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG high quality wheel loader 8 ton LW800K large front
loader.
XCMG LW800K is the most popular model of China 8t big
wheel loader. Now LW800KN is upgrading to a new model LW800KV equipped with a
EURO III engine with an electric injector, the new model will have high
performance.
Performance Characteristics:
* High performance Cummins QSM11 (Tier 3) engine
Enables the whole machine to have powerful traction force
and rapid hydraulic response.
* Low fuel consumption
During low speed traveling to remarkably reduce the fuel
consumption.
* High-efficiency hydraulic system
Realize low hydraulic power consumption, low energy
consumption, and improved efficiency of the hydraulic system.
* Low emission
Compliance with environment protection requirements and
output of clean emission.
|
Description |
Unit |
Parameter value |
|
Rated capacity |
kg |
8000 |
|
Bucket volume |
m3 |
4.5 |
|
Operating weight |
kg |
28500 |
|
Max. horse power |
kN |
242 |
|
Max. breakout force |
kN |
260 |
|
Hydraulic cycle time-raise |
kN |
6 |
|
Total hydraulic cycle time |
s |
10.8 |
|
Tire model |
29.5R25 |
|
|
Dimension LxWxH |
mm |
9300*3500*3770 |
|
Wheelbase |
mm |
3600 |
|
Hinge height at maximum liting height |
mm |
4516 |
|
Hinge height during loading |
mm |
500 |
|
Ground clearance |
mm |
520 |
|
Traction pin height |
mm |
1200 |
