XCMG Official 90m3Concrete Mixing Batch Plant HZS90 mobile Concrete Batching Plant
.jpg)
Summary
- Certification:CE/ISO
- Dimension(L*W*H):9050*2490*3750mm
- Power(W):2*30KW
- Model Number:HZS90
- Brand Name:XCMG
- Place of Origin:Jiangsu, China
- Power Type:Diesel
Specifications
- Weight:1.000kg
- Condition:New
- Moving Type:Other
- Working cycle time:72S
- Machine Type:Batching machine
- Mixing capacity:1500 L
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG HZS90 Concrete Mixing Batch Plant 90m3 Fixed Concrete
Batching Plant.
HZS90KE
concrete mixing plant is a new kind of concrete mixing equipment researched and
developed independently by our company on the basis of absorbing the advantages
of foreign and domestic mixing plants of the same type.
HZS90KE
cement concrete mixing plant has the features of little area occupied, simple
base, deliver fast easy to relocate and low energy consumption.
The
components of HZS90KE concrete mixing plant are:
1.
Storage, weighing and conveying system of aggregate;
2.
Storage, weighing and conveying system of powder;
3.
Water supply, weighing and discharging system;
4.
Additive storage, supply and weighing system;
5.
Mixing and dust-collecting system;
6.
The main tower structure;
7.
The pneumatic system;
8. The electric control system.
|
Items |
Unit |
HZS90KE |
|
Theoretical productivity |
m3/h |
90 |
|
Dump height |
m |
4 |
|
Model of main mixing machine |
JS1500 |
|
|
Mixing power |
kW |
2×30 |
|
Nominal volume of main mixing machine |
L |
1500 |
|
Production cycle |
s |
60 |
|
Aggregate diameter |
mm |
≤60 |
|
Aggregate bin volume |
m3 |
3×10 |
|
Powder bin capacity |
t |
2×100 |
|
Batching capacity of batching station |
t/Silo |
2400 |
|
Lifting bucket conveying capacity |
t/h |
150 |
|
Productivity of cement screw conveyor |
t/h |
90 |
|
Standard installed capacity |
kW |
138 |
|
Weighing range & accuracy of
sand/stone |
kg |
(500~4000)±2% |
|
Weighing range & accuracy of
cement |
kg |
(200~800)±1% |
|
Measurement range and accuracy of fly
ash |
kg |
/ |
|
Weighing range & accuracy of water |
kg |
(100~400)±1% |
|
Weighing range & accuracy of
additives |
kg |
(10~30)±1% |
