XCMG Schwing shotcrete truck HPS30V China new 82kW truck mounted concrete spraying machine price
Summary
- Certification:CE/ISO9001
- Dimension(L*W*H):8720×2595×3190mm
- Weight:16550kg
- Power(W):82kw
- Model Number:HPS30V
- Brand Name:XCMG
- Place of Origin:Xuzhou,Jiangsu,China
- Air Consumption:选配
Specifications
- Weight:16550.000kg
- Condition:New
- Moving Type:Other
- Turning radius:5.9m
- Max. speed/hour:25km/h
- Max. spraying height:17m
- Max. spraying width:30m
- Max. reach depth:8m
- Max. front spraying:15m
- Wind supply capacity:13.3m3/min
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
shotcrete truck HPS30V China new 82kW truck mounted
concrete spraying machine.
XCMG HPS30V Truck mounted concrete spraying machine
shotcrete truck can realize the max. spraying height of 18m, the farthest front
spraying distance of 15m and wider spraying range.
Performance and characteristic:
1. Besides the main power by motor, chassis power can
realize boom and outrigger telescoping.
2.More practical dual power technology., more efficient
skirt valve pumping system
3. Realize more flexible spraying operation without dead
angle and meet tunnel construction requirements to the greatest degree.
4. By incorporating Schwing's fully-hydraulic reversing
technology, short reversing time, small spraying impulse, low rebound ratio and
good spraying planeness are realized.
5. Quick-open type design can easily realize replacement
of delivery pipe, product maintenance and lubricant adding, etc.
|
Item |
Unit |
HPS30V |
|
Outline
dimension |
mm |
8720×2595×3190 |
|
Overall weight |
kg |
16550 |
|
Rated power of
engine |
kW/rpm |
82 /2300 |
|
Emission
standard |
—— |
China III |
|
Gradeability |
％ |
34.4 |
|
Turning radius |
m |
5.9 |
|
Max. speed/hour |
km/h |
25 |
|
Max. spraying
height |
m |
17 |
|
Max. spraying
width |
m |
30 |
|
Max. front
spraying distance |
m |
15 |
|
Min. permissible
tunnel height for spraying operation |
m |
4 |
|
Max. reach depth |
m |
8 |
|
Max. theoretical
spraying capacity |
m3/h |
30 |
|
Wind supply
capacity |
m3/min |
13.3 |
|
Delivery
pressure |
MPa |
0.8 |
