XCMG 12 ton wheel excavator HNE120W with Cummins engine for sale
Summary
- Rated Speed:35km/h
- Machine Weight:11200kg
- Maximum Digging Depth:4477mm
- Maximum Digging Height:6500mm
- Bucket Capacity:0.45m3
- Operating Weight:11200kg
- Model Number:HNE120W
- Brand Name:XCMG
- Place of Origin:Xuzhou, Jiangsu,China
Specifications
- Weight:11200.000kg
- Condition:New
- Moving Type:Other
- Engine rated power:74kW/2200r/min
- Max. digging force:63.5KN
- Max.Grade ability:57%
- Fuel tank capacity:190L
- Overall dimension:7026*2380*3390mm
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG 12 ton wheel excavator HNE120W with Cummins engine.
HNE120W wheel excavator less vibration and noise,
comparing with the same type of excavator in domestic, more comfortable. More
powerful, more than 15% torque reserve ratio, meet the requirement of the power
to the machine.
1.More powerful, meet the requirement of the power to the
machine.
2.Superior economic performance, the minimum fuel
consumption at full load is lower.
3.Less vibration and noise, comparing with the same type
of excavator in domestic, more comfortable.
4.Reliable and durable, Overhaul time is more than10.000
working hours in ordinary working condition.
5.Features of high rotate speed, large torque converter,
reliable quality.
6.Increase the reliability of the structure.
|
Working Range |
|
|
Boom length |
4260mm |
|
Arm length |
2580mm |
|
Max.Digging Reach |
7156mm |
|
Max.Digging depth |
4477mm |
|
Max.Digging height |
6500mm |
|
Max.Dumping height |
7316mm |
|
Max. Digging Reach on the Ground |
7156mm |
|
Performance |
|
|
Operating weight |
11200kg (with blade and outrigger) |
|
Engine model |
Cummins QSB3.9-C100 |
|
Engine rated power |
74kW/2200r/min |
|
Bucket capacity |
0.45m³ |
|
Traveling speed |
35Km/h |
|
Max. digging force |
63.5KN |
|
Max.Grade ability |
57% |
|
Ground pressure |
45Kpa |
|
Fuel tank capacity |
190L |
|
Dimension |
|
|
Overall width |
2380mm |
|
Overall height |
3390mm |
|
Overall length |
7026mm |
|
Min.Ground clearance |
380mm |
|
Wheel base |
2600mm |
