XCMG Official HBT10020V China brand Concrete Machinery trailer concrete pump for sale
![](/app/topc/statics/images/close.png)
![XCMG Official HBT10020V China brand Concrete Machinery trailer concrete pump for sale](http://www.machmall.com/images/store/357636/item/9c245bda7e9c8ece19a956493c27a75d.jpg)
![](/app/topc/statics/images/close.png)
Summary
- Certification:ISO/CE9001
- Dimension(L*W*H):6482×2100×2886MM
- Weight:7450KG
- Model Number:HBT10020V
- Brand Name:XCMG
- Place of Origin:JiangSu,China
Specifications
- weight:7450.000kg
- Condition:New
- Moving Type:Wheel
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG Official HBT10020V China brand Concrete Machinery trailer concrete pump.
1.Steadier Reversing Buffering Technology
The valve control buffering technology with faster response replaces traditional pump emission reduction technology;The buffering process is steadier and more reliable, with smaller impact;The reversing time is shortened to be less than 0.1s and the efficiency is improved by more than 6%.
2.More Reliable Fully-Hydraulic Reversing Technology
SCHWING Germany’s hydraulic technology quintessence truly realizes fully-hydraulic reversing, in which self-adaption control in fully-hydraulic closed-loop is realized, with no need for any electrical components, more effective, steadier and zero-pollution.
3.More Sophisticated Energy-Saving Control Technology
SCHWING Germany’s hydraulic technology quintessence truly realizes fully-hydraulic reversing, in which self-adaption control in fully-hydraulic closed-loop is realized, with no need for any electrical components, more effective, steadier and zero-pollution.
4.More and Smater Electrical Control
It can monitor and store equipment’s running state in real time, realize production reappearance and timely remind the equipment of operation and maintenance;It can accurately locate over 200 kinds of faults, thus saving troubleshooting time;By the remote consultation platform, it can realize online service by technicians and rapidly handle complicated faults.
CATEGORY |
ITEM |
UNIT |
HBT10020V |
Overall parameter |
Outline dimension |
mm |
6482×2100×2886 |
Overall weight |
kg |
7450 |
|
Power system |
Model |
|
BF6M1013 |
Rated power |
kW/r/min |
186/2100 |
|
Rated torque |
Nm/r/min |
1000/1600 |
|
Emission standard |
|
China III |
|
Pumping system |
Theoretical output(low/high pressure) |
/h3 |
100/55 |
Theoretical pumping pressure(low/high pressure) |
MPa |
11∕20 |
|
Delivery cylinder diameter ×stroke |
mm |
Φ230×1600 |
|
Filling height |
mm |
1370 |
|
Others |
Transfer tube |
|
Rock valve |
Lubrication type |
|
Automatic lubrication |
