XCMG official concrete pump truck HB52V China new 52m concrete machine with HOWO chassis price
Summary
- Dimension(L*W*H):13000×2540×4000mm
- Weight:35000kg
- Power(W):324kW
- Model Number:HB52V
- Brand Name:XCMG
- Place of Origin:Xuzhou, Jiangsu, China
- Certification:CE/ISO9001
Specifications
- Weight:35000.000kg
- Condition:New
- Moving Type:Other
- Color:Red
- chassis brand:HOWO
- Wheelbase:4800+1400mm
- Theoretical:170m³/h
- Reach height:51.2m
- Reach depth:36.1m
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
concrete pump truck HB52V China new 52m concrete machine
with HOWO chassis.
The XCMG HB52V concrete pump truck is equipped with more
efficient skirt valve and S valve pump technology, more stable reversing buffer
technology, more reliable full hydraulic reversing technology.
It adopts Sinotruk HOWO chassis, which complies with
China VI emission standard, featuring with powerful output,
large torque, high efficiency, energy conservation and strong off-road
performance.
Advantages
and highlights:
1.Ultimately Safe Boom.
2. Lower Structure of High
Rigidity.
3.Hydraulic System of
Outstanding Performance.
4.Effectively reduce
emissions with the reversing, vulnerability of longer life.
5.The pumping system
adopts electric control reversing, reversing faster and the system impact
smaller.
6.The actual pumping
efficiency is more than 5% higher than the conventional hydraulic control
reversing system.
|
Item |
Unit |
HB52V |
|
Outline
dimension |
mm |
13000*2540*4000 |
|
Overall weight |
kg |
35000 |
|
Brand |
/ |
Sinotruk HOWO |
|
Model |
/ |
ZZ5356V524MF1 |
|
Wheelbase |
mm |
4800+1400 |
|
Max.power |
kW |
324 |
|
Emission
standard |
/ |
China VI |
|
Theoretical |
m³/h |
170 |
|
Concrete pumping
pressure |
MPa |
8 |
|
Theoretical
pumping times |
Times/min |
23～26 |
|
Delivery
cylinder diameter × stroke |
mm |
φ260×2000 |
|
Reach height |
m |
51.2 |
|
Reach depth |
m |
36.1 |
|
Slewing radius |
m |
46 |
|
Slewing angle |
° |
±270 |
|
Transfer |
/ |
Rock valve/S valve |
