XCMG Official 52m Cheap Price Concrete Pump Machine HB52K concrete pump truck price for sale
Summary
- Dimension(L*W*H):13120×2500×3990MM
- Weight:34000KG
- Power(W):297000W
- Model Number:HB52K
- Brand Name:XCMG
- Place of Origin:JiangSu,China
- Certification:CE/ISO9001
Specifications
- Weight:34000.000kg
- Condition:New
- Moving Type:Other
- Color:Color
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG Official 52m Cheap Price Concrete Pump Machine HB52K
concrete pump truck.
XCMG
V7 series truck mounted concrete pump is a new generation equipment which is
developed by XCMG and SCHWING Germany technology.
It
is highly reliable and durable with seven technical highlights. More advanced
boom structure technology, More efficient rock valve pumping technology,
Steadier stabilizer structure technology, Steadier reversing buffering
technology, more reliable fully-hydraulic reversing technology, Ultra-low
pressure loss hydraulic system technology, safer and smarter electrical control
system.
*
Large diameter (280 mm) Φ, large displacement (170 / hour) pumping systems.
*
Material absorption can reach more than 85%.
*
Effectively reduce emissions with the reversing, vulnerability of longer life.
*
The pumping system adopts electric control reversing, reversing faster and the
system impact smaller.
* The actual pumping
efficiency is more than 5% higher than the conventional hydraulic control
reversing system.
|
Description |
Unit |
Parameter value |
|
|
Outline dimension |
mm |
13120×2500×3990 |
|
|
Overall weight |
kg |
34000 |
|
|
Chassis |
Model |
ZZ5347V484MD1 |
|
|
Max. speed |
km/h |
90 |
|
|
Max. grade-ability |
% |
40 |
|
|
Wheelbase |
mm |
4800+1400 |
|
|
Tire |
315/80R22.5 |
||
|
Engine |
Model |
MC11.40-40 |
|
|
Max. power |
kW |
297 |
|
|
Max. torque |
N·m/(r/min) |
1900/1000~1400 |
|
|
Displacement |
L |
10.518 |
|
|
Emission standard |
Eruo IV |
||
|
Pumping system |
Theoretical output |
m³/h |
170 |
|
Concrete pumping pressure |
MPa |
8 |
|
|
Theoretical pumping times |
Time/min |
23~26 |
|
|
Delivery cylinder diameter ×stroke |
mm |
φ260×2000 |
|
|
Max. diameter of pumping concrete |
mm |
≤40 |
|
|
Filling height |
mm |
1580 |
|
|
Concrete slump range |
cm |
8~23 |
|
|
Placing boom |
Reach height |
m |
51.5 |
|
Reach depth |
m |
36.1 |
|
|
Slewingradius |
m |
46 |
|
|
Slewing angle |
° |
±270 |
|
|
Unfolding angle of the 1st section |
° |
90 |
|
|
Unfolding angle of the 2nd section |
° |
180 |
|
|
Unfolding angle of the 3rd section |
° |
180 |
|
|
Unfolding angle of the 4th section |
° |
240 |
|
|
Unfolding angle of the 5th section |
° |
210 |
|
|
Unfolding angle of the 6th section |
° |
120 |
|
|
Stabilizer span |
Longitudinal span of stabilizer |
mm |
9540 |
|
Transverse span of front stabilizer |
mm |
9150 |
|
|
Transverse span of rear stabilizer |
mm |
10060 |
|
|
Others |
Lubrication method |
Automatic lubrication |
|
|
Control method |
Manual/remote control |
||
|
Volume of water box |
L |
1200 |
|
