XCMG Motor Graders 220 HP China Road Construction Machines GR2205 With Hydraulic Pump Price
Specifications
- Weight:16500.000kg
- Condition:New
- Moving Type:Other
- power/Speed:164/2200kW/rpm
- Dimension(L*W*H):9300X2625X3470mm
- Brand Name:XCMG
- Place of Origin:Jiangsu, China
- Certification:ISO/CE
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG Motor Graders 220
HP China Road Construction Machines GR2205 With Hydraulic Pump Price.
GR2205 Motor grader, which belongs to the XCMG
new generation "Series 5", incorporates several advanced
energy-saving technologies such as variable power control, load sensing and
independent cooling, greatly reducing the user's cost.
The application of various advanced shock
absorption and noise reduction technologies, comfortable control arrangement
and better driving environment brings more comfortable control environment to
the users.
Less required operating force greatly reduces
the labor intensity of the operator; perfect weight matching allows the machine
with strong operating capacity.
GR2205 integrates energy-saving, low noise,
comfort, reliability, is the preferred choice for large areas leveling
operation in highway, airports, farmland.
|
Engine model |
D6114 |
|
Rated power/speed |
125kW/2300rpm |
|
Dimension(LxWxH) |
8900×2625×3470mm |
|
Operating weight(Standard) |
15000kg |
|
Performance specification |
|
|
Travelling speed ,forward |
5,8,11,19,23,38 km/h |
|
Travelling speed ,reverse |
5,11,23 km/h |
|
Tractive force(f=0.75) |
77KN |
|
Max. gradeability |
20% |
|
Tire inflation pressure |
260 kPa |
|
Working hydraulic pressure |
16 MPa |
|
Transmission pressure |
1.3~1.8MPa |
|
Operating specification |
|
|
Max. steering angle of front wheels |
±50° |
|
Max. lean angle of front wheels |
±17° |
