XCMG 215hp Grader Motor GR215 China Motor Grader Road Construction With Cummins Engine Price
Specifications
- Weight:16500.000kg
- Condition:New
- Moving Type:Other
- Brand Name:Brand Name
- Place of Origin:Place of Origin
- Certification:Certification
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG 215hp Grader Motor GR215 China Motor Grader
Road Construction With Cummins
Engine Price.
GR215 is mainly used for large ground surface leveling,
ditching, slope scraping, bulldozing, scarifying, snow removing and other work
in highway, airport and farmland. The grader is necessary engineering machinery
for national defense construction, mine construction, urban and rural road
construction, water conservancy construction and farmland improvement, etc.
Advantages and Highlights:
1. Dongfeng cummins engine,
ZF technology gearbox and Meritor drive axle make the dynamic matching of
transmission system more reasonable and reliable.
2. Take measures such as vibration elimination, sound
absorption and sound insulation to reduce the internal and external noise of
the cab.
3. The double-circuit hydraulic brake system is applied
to realize more reliable and stable braking.
4. The steering load-sensing system is applied and the
main hydraulic units adopt international products to guarantee the system
stability and reliability.
5. The XCMG's special enhanced working device is applied.
6. The blade body adopts adjustable large slide slot and
double slideway mechanism and the blade plates are made of wear-resistant high
strength materials.
7. The multiple optional parts expand the performance and
working scope of machine.
|
Item |
GR215 |
||
|
Basic parameters |
Engine model |
6CTA8.3-C215 |
|
|
Rated power/speed |
160kW/2200rpm |
||
|
Overall dimension (standard) |
8970x2625x3420 |
||
|
Total weight (standard) |
16500 kg |
||
|
Tire specification |
17.5-25 |
||
|
Ground clearance (front axle) |
430mm |
||
|
Space of front and rear axles |
6219 mm |
||
|
Space of middle and rear wheels |
1538 mm |
||
|
Performance parameters |
Forward velocity |
5,8,11,19,23,38km/h |
|
|
Reverse speed |
5,11,23km/h |
||
|
Tractive effort f=0.75 |
87 kN |
||
|
Maximum gradeability |
20% |
||
|
Tire inflation pressure |
260kPa |
||
|
Working system pressure |
16MPa |
||
|
Transmission pressure |
1.3—1.8Mpa |
||
|
Working parameters |
Maximum steering angle of front wheel |
±50° |
|
|
Maximum slant angle of front wheel |
±17° |
||
|
Maximum oscillating angle of front axle |
±15° |
||
|
Maximum oscillating angle of equilibrium box |
forwards15°, Reverse15° |
||
|
Maximum steering angle of frame |
±27° |
||
|
Minimum turning radius |
7.3m |
||
|
Scrape knife |
Maximum lift height |
450mm |
|
|
Maximum cutting depth |
500mm |
||
|
Maximum tilt angle |
90° |
||
|
Cutting angle |
28°—70° |
||
|
Angle of revolution |
360° |
||
|
Length & chord height |
4270x610mm |
||
|
Oil filling amount |
Coolant |
50L |
|
|
Fuel tank |
280L |
||
|
Engine |
24L |
||
|
Transmission |
38L |
||
|
Equilibrium box |
46L |
||
|
Coolant |
28L |
||
|
Hydraulic oil |
110L |
||
