XCMG new 10 ton forklifts FD100T China diesel forklift truck machine with Japan Engine for sale
Summary
- Fork Width:175mm
- Fork Length:1220mm
- Min Lifting Height:2845mm
- Max Lifting Height:4260mm
- Rated Loading Capacity:10000kg
- Power Source:Diesel Engine
- Model Number:FD100T
- Brand Name:XCMG
- Place of Origin:Jiangsu, China
Specifications
- Weight:12900.000kg
- Condition:New
- Moving Type:Other
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG manufacturer 10 ton forklifts FD100T China diesel
forklift truck machine with Japan Engine.
1.XCMG Diesel Forklift provide you with multiple choice
as per your real need, we have different reliable engines for choice. All these
engines have been tested that they can be trusted through all kinds of tough
working condition and get recognition from millions of client across the
worldwide.
2.These engines are specifically designed for the
forklift use, with low fuel consumption, less noise and vibration, all these
features improve the whole performance of the forklift.
3.High efficiency is also delivered through the
performance of the axles, the excellent brake system makes sure the forklift
operates with safety, the steering axle provide prompt and precise feedback to
the driver when steering.
Advantages and Highlights:
1.One-piece designed of suspension frame.
2.New water tank & cooling system.
3.Larger operation space. Optimized steering wheel,
operating handle and pedals.
4.High-efficiency hydraulic system, lower fuel
consumption.
5.Enhanced wide
view mast improves the work efficiency and operating safety.
|
Model |
Unit |
FD100T-H |
FD100T-JF |
FD100T-JI |
FD100T-JT |
|
Power Type |
Diesel |
||||
|
Rated Load Capacity |
kg |
10000 |
|||
|
Load Centre |
mm |
600 |
|||
|
Rated Lift Height |
mm |
3000 |
|||
|
Free Lift Height |
mm |
120 |
|||
|
Fork Size (L×W×T) |
mm |
1220×175×80 |
|||
|
Mast Tilt Angle (F/R, α°/β°) |
deg |
6°/12° |
|||
|
Fork Overhang (Wheel Center
to Fork Face) |
mm |
721 |
|||
|
Rear Overhang |
mm |
760 |
|||
|
Ground Clearance (Bottom of
Mast) |
mm |
250 |
|||
|
Length to Face of Fork
(Without Fork) |
mm |
4270 |
|||
|
Overall Width |
mm |
2165 |
|||
|
Mast Lowered Height |
mm |
2845 |
|||
|
Mast Extended Height (With
Backrest) |
mm |
4260 |
|||
|
Overhead Guard Height |
mm |
2540 |
|||
|
Turning Radius (Outside) |
mm |
3900 |
|||
|
Travel Speed (No Load) |
km/h |
20 |
|||
|
Lifting Speed (Full Load) |
mm/sec |
310 |
|||
|
Total Weight |
kg |
12900 |
|||
|
Battery |
V/Ah |
24/90 |
|||
|
Engine Model |
6102BG6 |
A-6BG1QC |
QSB4.5 |
TCD 3.6L4 |
|
|
Engine Manufacturer |
CHAOCHAI |
ISUZU |
CUMMINS |
DEUTZ |
|
