XCMG 70 ton Second Hand XE700D Large Hydraulic Crawler Excavator

FOB Price: $114000.000

View All >

Model： XE700D

After-sales Service： Engineers available to service machinery overseas

Min Order Quantity： 1 Unit

Delivery Time：

In Stock (Within 7 days)

Production (Within15 to 20 days)

Customization (negociated delivery time)

After-sales Service：

1. It is recommended that you keep in touch with the seller after purchasing offline...

About after-sales service:

1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:

1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.

Inquiry Chat Now

Favorite Products

Product:

XCMG 70 ton Second Hand XE700D Large Hydraulic Crawler Excavator

Quantity:

- + /Unit

Content:

Or choose from these questions:

What is the best price you can offer?

Do you support customization?

What is the MOQ for this product?

*Email:

Full Name:

Mobile phone:

XE700D

Specs & Compare

Details

Specs & Compare

Select 3 models for comparison

Model Number

Brand Name

Place of Origin

Machine Weight

Maximum Digging Depth

Maximum Digging Height

Bucket capacity

Operating Weight

Max Digging Radius

Rated Speed

Certification

Used Equipment

XE700D

XCMG

Jiangsu, China

69000 kg

6950 mm

11300 mm

2.4-4.6 m³

69000 kg

11580 mm

+ Add a Product

Summary

Model Number:XE700D
Brand Name:XCMG
Place of Origin:Jiangsu, China
Machine Weight:69000 kg
Maximum Digging Depth:6950 mm
Maximum Digging Height:11300 mm
Bucket capacity:2.4-4.6 m³
Operating Weight:69000 kg
Max Digging Radius:11580 mm

Specifications

Weight:69000.000kg
Condition:Used
Moving Type:Other
Year:2018/2/2

Packaging & Shipping

Delivery Lead Time:7 days for ready goods
Minimum Order:1 Piece
Delivery Port:Any Port In China

XCMG 70 ton Second Hand XE700D Large Hydraulic Crawler Excavator

1. It carries an original engine imported from America that meets TIER 3 emission standard. It is featured in strong power, low noise, low oil consumption and low emission and can satisfy the requirements of diversified operation modes. The engine is integrated with a high pressure fuel injection system, by controlling fuel supply actuator and timing actuator, ECM can achieve pure electric control of the full fuel injection process, precisely control injection amount and time of injection, reduce fuel consumption and increase engine efficiency.

2. Imported original hydraulic components and technologically advanced negative flow control system have not only extended service life of the entire vehicle but also improved its working efficiency; the new type main valve has a series of regenerative, convergent and prioritized functions that reduce energy consumption requirements; hydraulic oil cooling system has an independent cooling system, which can automatically control fan rotating speed according to oil temperature, reduce energy consumption and lower noises; what’s more, the fan can reversely rotate, and is convenient for the dust to be wiped off from the cooler.

3. It has a three-level fuel filtration system (one level of coarse filtration and two levels of fine filtration) that can effectively screen impurities out of fuel and guarantee long term, high load and continuous reliable engine operation under harsh working conditions. It has adopted a visible oil-water separator of the latest technology, with which, when to replace filter element can be determined from fuel level. During the full service life of filter element, oil intake resistance remains unchanged, which lowers the cost of filter element and reduces maintenance cost for customers.

4. The combination of oil bath type air filter + radial sealing type air filter system not only reduces maintenance cost, but also increases filtration rate to 99.99%, adaptable to dusty and damp working conditions.

5. The electric control system, which has a good performance and a reliable quality, realizes the perfect matching of power and hydraulic system, makes the best of engine power and guarantees quick and high efficient working operation.

Description		Unit	Parameter value
Operating weight		kg	69000
Bucket capacity		m³	2.4-4.6
Engine	Model	Engine	QSX15
	Direct injection	---	√
	Four strokes	---	√
	Water cooling	---	√
	Turbo-charging	---	√
	Air to air intercooler	---	√
	No. of cylinders	---	6
	Output power	kW/ r/min	336/1800
	torque/speed	N.m	2102/1400
	Displacement	L	15
Main performance	Travel speed(H/L)	km/h	4.2/3.0
	Gradeability	%	35
	Rotary speed	r/min	7
	Ground pressure	kPa	101.4
	Bucket digging force	kN	363
	Arm digging force	kN	300
	Travel traction force	kN	450
Hydraulic system	Main pump	--	2
	Rated flow of main pump	L/min	2×450
	Pressure of prime valve	MPa	31.4/34.3
	Pressure of travel system	MPa	34.3
	Pressure of swing system	MPa	28.5
	Pressure of pilot system	MPa	3.9
Oil Capacity	Fuel tank capacity	L	950
	Hydraulic tank capacity	L	500
	Engine oil capacity	L	48
Appearance size	Overall length	mm	12130
	Overall width	mm	4410
	Overall height	mm	4700
	Width of platform	mm	4410
	Length of crawler	mm	5955
	Overall width of chassis	mm	4000
	Width of crawler	mm	650
	Wheel base of crawler	mm	4685
	Crawler gauge	mm	2800/3350
	Clearance under counterweight	mm	1565
	Min. ground clearance	mm	853
	Min. tail swing radius	mm	4090
Working scope	Max. digging height	mm	11300
	Max. dumping height	mm	7320
	Max. digging depth	mm	6950
	Max. digging depth at the range of level 8 feet	mm	6800
	Max. vertical wall digging depth	mm	5550
	Max. digging reach	mm	11580
	Min. swing radius	mm	4750

XCMG STORY

XCMG RECONDITIONED MACHINE

XCMG reconditioned machine is the second-hand machine program launched by XCMG for the post market. XCMG takes advantage of its dealers network to collect the second-hand XCMG machine that falls into strict standards: good condition, full function and low service hours. The returned machine is then disassembled, repaired, painted, rebuilt and tested officially by XCMG, and the product life is therefore extended. The price of XCMG reconditioned machine is far lower than that of the new one, but its performance and safety are not compromised thanks to XCMG's state-of-the-art processes and technologies. In order to dispel customers' concerns, XCMG establishes a strict evaluation system for reconditioned machines and invites SGS to issue third-party certification.

OUR TEAM

150+ SPECIALISTS

150+ specialists participate in the reconditioning process.

Inspection Team

Certified professional accessors who have worked for more than 10 years conduct comprehensive analysis on the machine.

Reconditioning and Repairing Team

Refurbish core parts to restore capacity. Replace all worn parts with genuine XCMG new ones.

Issuing Report Team

Certified examiner inspects, tests and certifies the reconditioned machine. SGS provides the third-party inspection certificate.

OUR FACTORY

REMANUFACTURING FACTORY

RECONDITION PROCESSES

RECONDITION PROCESSES OF THE USED

We maintain a meticulous and rigorous attitude toward quality, focusing on extraordinary creativity, elaborate designs and exquisite craftsmanship.

COLLECTION

Examine the working conditions, conduct static and dynamic assessment on the used machine. Only machines with light deprecation, low working hours and full functions can be collected.

INSPECTION

Certified professional accessors who have worked for more than 10 years conduct comprehensive analysis on the machine. More than 300 details are checked and compared to XCMG standard. Recondition plan is then decided.

RECONDITIONING AND REPAIRING

Refurbish core parts to restore capacity. Replace all worn parts with genuine XCMG new ones.

TESTING

Follow the test procedure, ensure the performance and durability of the machine. Unqualified products are returned to step 3.

READY FOR DELIVERY

Ready for Delivery!!!

ISSUING REPORT

Certified examiner inspects, tests and certifies the reconditioned machine. SGS provides the third-party inspection certificate.

PAINTING

The whole machine is repainted to restore its appearance. Bright as new.

FAQ

FREQUENTLY ASKED QUESTIONS

1.What’s the warranty policy for XCMG reconditioned machines?

The warranty policy does not cover the covering parts and wearing parts. For engine, gearbox, hydraulic pump, distriutor valve and electric system, the warranty period will be 3 months or 500 working hours whichever comes first. If there is any problem within warranty period, XCMG will provide solutions accordingly.

2.How about the quality of your machine?

The procedure of recondition is taking the same criterion of brand new XCMG machines, therefore, quality of machines will be guaranteed. They are ready to work for you and XCMG will provide test report from professtional institute.

3.Are you the original manufacturer?

Yes! XCMG is leading construction machinery industry in China and XCMG can provide a complete range of constrcution machineries.

4.Can you satisfy my special requirement?

As the manufacturer,XCMG will review the special requirement and recondition it as per request (if possible).

5.What is accpetable payment terms?

Usually XCMG will accept T/T before shipment or 100% Letter of Credit at sight.
If any other questions, please feel free to contact with us.
