XCMG LW180K 2t mini payloader machine made in China
![](/app/topc/statics/images/close.png)
![XCMG LW180K 2t mini payloader machine made in China](http://www.machmall.com/images/store/357636/item/LW180K 首图.jpg)
![](/app/topc/statics/images/close.png)
Summary
- Rated Load:1800kg
- Dimension(Long* Breadth * High):5980*2060*2950mm
- Type:front loader
- Place of Origin:Jiangsu, China
- Model Number:LW180K
- Brand Name:XCMG
- Certification:CE/ISO9001
Specifications
- weight:1800.000kg
- Engine Brand:Other
- Rated Load:1-2 ton
- Bucket Capacity:0.5 - 2m³
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG Official LW180K 2t mini payloader machine.
Performance Highlights:
1. The extended wheelbase (2,300mm) design applied adapts to diversified
super-heavy working conditions, with the stability leading the industry.
2. With powerful digging force (The breakout force of
LW180K is ≥58kN) and strong breaking force, it handles diversified materials
with ease.
3. It boasts the industry’s best traveling speed
(26km/h), featuring high rapidness and efficiency.
4. The diversified dumping heights (at 2,650~2,970mm) are
at choice to meet the operation needs in diversified applications.
Model | Unit | LW180K | |
Rated load | kg | 1800 | |
Standard bucket capacity | m³ | 1.0 | |
Operating weight | kg | 6000 | |
Engine Model | / | YC4D80-T20 | |
Rated power/speed | kw/rpm | 58/2400 | |
Dumping clearance at max.lift | mm | 2580 | |
Reach at max.lift | mm | 865-970 | |
Wheel base | mm | 2300 | |
tread | mm | 1550 | |
Max.breakout force | kN | 58 | |
Hydraulic cycle time-raise | s | 5 | |
Total hydraulic cycle time | s | 8.5 | |
Min.turning radius over tyres | mm | 4700 | |
Articulation angle | 0 | 35 | |
gradeability | 0 | 28 | |
Tyre size | 16/70-20 | ||
Overall dimension LxWxH | mm | 5850x2060x2950 | |
Travel speed | I-gear (F/R) | Km/h | 0-9/0-9 |
II-gear (F/R) | 0-26/0-26 |
