Generals Model Unit HH30 HH30Z Power type Diesel Rated capacity Kg 3000 Load center mm 500 Dimensi, MACHMALL

Storage & Logistics Equipment > Material Transfer Machinery > Forklift

Generals Model Unit HH30 HH30Z Power type Diesel Rated capacity Kg 3000 Load center mm 500 Dimensi

View All >

Model： HH30Z-W1-D

After-sales Service： Engineers available to service machinery overseas

Min Order Quantity： 1 Unit

Delivery Time：

In Stock (Within 7 days)

Production (Within15 to 20 days)

Customization (negociated delivery time)

After-sales Service：

1. It is recommended that you keep in touch with the seller after purchasing offline...

About after-sales service:

1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:

1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.

Inquiry Chat Now

Favorite Products

Product:

Generals Model Unit HH30 HH30Z Power type Diesel Rated capacity Kg 3000 Load center mm 500 Dimensi

Quantity:

- + /Unit

Content:

Or choose from these questions:

What is the best price you can offer?

Do you support customization?

What is the MOQ for this product?

*Email:

Full Name:

Mobile phone:

HH30Z-W1-D

Specs & Compare

Details

Specs & Compare

Select 3 models for comparison

Fork Width

Fork Length

Min Lifting Height

Max Lifting Height

Rated Loading Capacity

Power Source

Type

Model Number

Brand Name

Place of Origin

Storage & Logistics Equipment

HH30Z-W1-D

120MM

1070MM

6000mm

3 Ton

Diesel Engine

Ordinary Product

HH30Z-N1-D

HUAHE

Zhejiang, China

+ Add a Product

Summary

Fork Width: 120MM
Fork Length: 1070MM
Min Lifting Height:3M
Max Lifting Height:6000mm
Rated Loading Capacity:3 Ton
Power Source:Diesel Engine
Type:Ordinary Product
Model Number:HH30Z-N1-D
Brand Name: HUAHE
Place of Origin: Zhejiang, China

Specifications

Weight:4300.000kg
Condition:New
Moving Type:Other

Packaging & Shipping

Delivery Lead Time:7 days for ready goods
Minimum Order:1 Piece
Supply Ability:10,000 Set/ Sets per Month
Total Quantity In Stock:Over 5000
Delivery Port:Any Port In China

Specification Of Forklift

	origin							ZHEJIANG HuaHe forklift company
	Model									HH30Z
	Power type									Diesel
	Rated capacity								kg	3000
	Load center								mm	500
Dimension	Lift height								mm	3000
	Free lift height								mm	130
	Fork size			NUL					mm	107012545
	Mast inclination			Front/Back					deg	6/12
	Front o-verhang								mm	490
	Overall dimensions			Length to face of fork					mm	2680
				Overall width					mm	1225
				Mast lowered height					mm	2120
				Overhead guard height					mm	2120
	Turning radius								mm	2460
	Min. right angle aisle width								mm	2105
Performance	Travel speed				No load				km/h	9/20
					Full load				mm/s	8.8/18.5
	Lift speed								mm/s	480
	Max. gradeability								%	20
	Max. drawbar pull								Kn	14
	self weight								kg	4400
Wheel&Tires	Tires	Front								28*9-15-12PR
		Rear								6.50-10-10PR
	Tread	Front							mm	1000
		Rear							mm	970
	Wheelbase								mm	1650
	Min. ground (no ldad/full load)						Mast		mm	152/132
							Frame		mm	158/138
Drive units	Battery		Voltage						V/Ah	12/90
	Engine		Model							C490BGP
			origin							CHINA
			Rated output/r.p.m						kw/r.p.m	37/2650
			Rated torque						N.m/r.p.m	139/1800
			No. of Cylinder							4
			Displacement						cc	2369
			Type							Hydraulic
			Shift			(Fwd/Rwd)				1/1
	Operating pressure								Mpa	17.5
